Please note – spec applies to all sizes unless listed separately.
Frameset
Frame: Premium Alpha Platinum Aluminium frame, top-load Bosch CompactTube battery, integrated cockpit routing, integrated rack and mudguards, 135x5 mm fixed-position derailleur dropout
Fork: SR Suntour SF25-NVX32, coil spring, preload adjuster, 5 mm ThruSkew, 63 mm travel
E-system
Motor: Bosch Performance Line, 250 W, 75 Nm, 20 mph / 25 km/h in Europe
Battery: Bosch PowerTube 800 Wh, Smart System
Charger: Bosch standard 2A, 230V, Smart System
Computer: Bosch Purion 200
Drivetrain and brakes
Shifter: Shimano Nexus C7000, 5-speed
Crank: ProWheel alloy, 170 mm length
Rear sprocket: Gates CDX, 32T, stainless steel
Belt: Gates CDC belt, 128T
Pedals: Bontrager City pedals
Maximum chainring size: See service manual
Brakes: Shimano MT200 hydraulic disc
Brake rotors: Sizes M, L and XL: Shimano RT30, CentreLock, 180 mm or Shimano CL300, CenterLock, 180 mm
Maximum brake rotor size: Frame: 203 mm / Fork: see fork manufacturer
Wheels and tyres
Front hub: Shimano Tourney HB-QC300, CenterLock
Front skewer: Trek Thru-Skew
Rear hub: Shimano Nexus C7000, 5-speed
Rims: Sizes M, L and XL: Bontrager Kovee, double-wall, Tubeless Ready, 28-hole, 23 mm width, Presta valve or Bontrager Kovee, double-wall, Tubeless Ready, 32-hole, 23 mm width, Presta valve
Spokes: 14 g stainless steel, black
Tyres: Bontrager E6 Hard-Case Lite, reflective strip, 27.5x2.40"
Maximum tyre size: Frame: 27.5x2.40" / Fork: see manufacturer
Cockpit
Handlebar: Alloy, 31.8 mm clamp, 25 mm rise, 630 mm width
Grips: Trek Ergonomic PRO, lock-on
Stem: Bontrager alloy, 31.8 mm clamp, adjustable rise, Blendr compatible, 80 mm length
Additional Features
Saddle: Bontrager Boulevard
Seatpost: Alloy, suspension, 31.6 mm, 300 mm length
Lights: Sizes M, L and XL: Trek LED taillight and Trek LED headlight
Kickstand: Pletscher Comp Flex 40
Mudguards: Trek Charter alloy mudguards
Weight
Weight: Size L – 28.60 kg / 63.06 lbs, excluding battery and pedals
Weight limit: This bike has a maximum total weight limit, including the bicycle, rider and cargo, of 136 kg / 300 lb.
We reserve the right to make changes to the product information at any time without notice, including equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted without notice.
Bike and frame weights are based on pre-production painted frames at the time of publication. Final production weights may vary.
