*Please note – spec applies to all sizes unless listed separately
Frameset
Frame: Premium Alpha Platinum Aluminum frame, top-load PowerPack, integrated cockpit routing, 135x5mm QR
Fork: SR Suntour Mobie 34, tapered steerer tube, air spring, adjustable rebound and compression, lockout, 100mm QR, 80mm travel
Wheels
Front Hub: Shimano TC500, CenterLock, 110x15 mm thru axle
Rear Hub: Shimano TC500-HM
Rear Skewer: Bontrager Switch thru axle, removable lever
Rims: Bontrager Kovee, double-wall, Tubeless-Ready, 23 mm width, Presta valve (32-hole or 28-hole depending on size)
Spokes: 14 g stainless steel, black
Tyres: Bontrager E6 Hard-Case Lite, reflective, wire bead, 60 tpi, 27.5x2.4"
Max Tyre Size: Frame: 27.5x2.40", Fork: see manufacturer
E-System
Battery: Bosch PowerTube 800 Wh, smart system
Motor: Bosch Smart System PX, 250 W, 90 Nm, max assist 25 km/h
Controller: Bosch Kiox 500, smart system
Computer / Remote: Bosch LED Remote, smart system
Charger: Bosch standard 4A, 230V, smart system
E-bike Classification: Class 1
Drivetrain
Shifter: Shimano CUES U6000 with optical gear display, 10-speed
Rear Derailleur: Shimano CUES U6000 GS
Crank: ProWheel alloy, 170 mm length
Chainring: Alloy with 40T narrow-wide steel ring, alloy guard
Cassette: Shimano CUES LG400 LINKGLIDE, 11–48t, 10-speed
Chain: Shimano LG500, 9/10/11-speed
Pedals: Bontrager City pedals
Max Chainring Size: 1x: 50T
Components & Brakes
Saddle: Bontrager Commuter Comp
Seatpost:
• Sizes S, M: Aluminium suspension seatpost, 300 mm, adjustable spring rate
• Sizes L, XL: Aluminium suspension seatpost, 350 mm, adjustable spring rate
Handlebar: Alloy, 31.8 mm clamp, 25 mm rise, 630 mm width
Grips: Trek Ergonomic PRO, lock-on
Stem: Bontrager alloy, 31.8 mm clamp, adjustable rise, Blendr compatible, 80 mm length
Brakes: Shimano MT401 / MT420 hydraulic disc
Brake Rotors: Shimano RT30 CentreLock, 180 mm / 203 mm (size dependent)
Max Rotor Size: Frame: 203 mm, Fork: see fork manufacturer
Accessories
Front Light: Trek LED, 400 lumen (low) / 800 lumen (high)
Rear Light: Trek LED taillight
Kickstand: Pletscher Comp Flex 40
Weight & Limits
Weight: Size M – 27.30 kg / 60.19 lb (excluding battery)
Weight Limit: Maximum total weight (bike + rider + cargo): 160 kg / 352 lb
Specifications may change without notice due to supply chain constraints.
Bike and frame weights are based on pre-production painted frames; final production weights may vary.
