*Please note – spec applies to all sizes unless listed separately
Frameset
Frame: Alpha Platinum Aluminium, Removable Integrated Battery (RIB 2.0), tapered head tube, guided internal routing, Control Freak internal routing, Motor Armour, Boost148, 12 mm thru axle
Fork:
- S: RockShox Recon Silver RL, Solo Air, Motion Control damper, lockout, tapered steerer, 46 mm offset, Boost110, 15 mm Maxle Stealth, 100 mm travel
- M, L, XL: RockShox Recon Silver RL, Solo Air, Motion Control damper, lockout, tapered steerer, 42 mm offset, Boost110, 15 mm Maxle Stealth, 120 mm travel
Max compatible fork travel: See service manual
Wheels
Hub front: Shimano TC500 alloy, CentreLock, 110x15 mm thru axle
Rim: Bontrager Line TLR 30, Tubeless-Ready, 28-hole, Presta valve
Spokes: 14 g stainless steel, black
Max tyre size: See service manual
E-system
Battery: Bosch PowerTube 800 Wh, smart system
Charger: Bosch standard 4A, 230V, smart system
Drivetrain
Shifter: Shimano Deore M6100, 12-speed
Rear derailleur: Shimano XT M8100, long cage
Cassette: Shimano Deore M6100, 10-51, 12-speed
Chain: Shimano Deore M6100, 12-speed
Pedal: VP-536 nylon platform
Max. chainring size: 1x: 42T
Components
Saddle: Bontrager Commuter Comp
Seatpost:
- S: Bontrager Line Dropper, 100mm travel, MaxFlow, internal routing, 31.6 mm, 310 mm length
- M, L, XL: Bontrager Line Dropper, 170 mm travel, MaxFlow, internal routing, 31.6 mm, 450 mm length
Handlebar: Bontrager Comp, alloy, 31.8 mm, 40mm rise, 780 mm width
Grips: Bontrager XR Endurance Comp, lock-on
Stem: Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length
Headset: FSA IS-2, 1-1/8" top, 1.5" bottom
Brakes
Brake: Shimano 4-piston hydraulic disc, MT4100 lever, MT420 calliper
Brake rotor: Shimano RT64, CentreLock, 203 mm
Rotor size: Max brake rotor sizes – Frame: 203 mm, min 180 mm, fork: see fork manufacturer
Weight
Weight limit: This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb)
