Please note – spec applies to all sizes unless listed separately.
Frameset
Frame: Alpha Platinum Aluminium, Removable Integrated Battery (RIB 2.0), tapered head tube, guided internal routing, Control Freak internal routing, Motor Armour, Boost148, 12 mm thru axle
Fork: Size S: RockShox Recon Silver RL, Solo Air, Motion Control damper, lockout, tapered steerer, 46 mm offset, Boost110, 15 mm Maxle Stealth, 100 mm travel / Sizes M, L and XL: RockShox Recon Silver RL, Solo Air, Motion Control damper, lockout, tapered steerer, 42 mm offset, Boost110, 15 mm Maxle Stealth, 120 mm travel
E-system
Motor: Bosch Performance Line CX, Europe and APAC: 25 km/h, US and rest of world: 20 mph / 32 km/h
Battery: Bosch PowerTube 800 Wh, smart system
Charger: Bosch standard 4A, 230V, smart system
Computer: Bosch Purion 200
E-bike classification: Class 1
Drivetrain and brakes
Shifter: Shimano Deore M6200
Rear derailleur: Shimano Deore M8200, long cage
Crank: FSA alloy, 160 mm length
Cassette: Sizes S, M, L and XL: Shimano XT M8100, 10-51, 12-speed or SunRace CSMZ800, 11-51, 12-speed
Chain: Shimano Deore M6100, 12-speed
Pedals: VP-536 nylon platform
Maximum chainring size: 1x: 42T
Brakes: Size S: Shimano hydraulic disc, MT4100 lever, MT420 4-piston calliper / Sizes M, L and XL: Shimano 4-piston hydraulic disc, MT4100 lever, MT420 calliper
Brake rotors: Shimano RT64, CentreLock, 203 mm
Maximum brake rotor size: Frame: 203 mm / Fork: see fork manufacturer
Wheels and tyres
Front hub: Shimano TC500 alloy, CentreLock, 110x15 mm thru axle
Rear hub: Shimano TC500 alloy, CentreLock, 148x12 mm thru axle
Rear skewer: Bontrager Switch thru axle, removable lever
Rims: Sizes S, M, L and XL: Bontrager Kovee, double-wall, Tubeless Ready, 23 mm width, Presta valve, 28-hole or 32-hole
Spokes: 14 g stainless steel, black
Tyres: Size S: Bontrager Gunnison Elite XR, Tubeless Ready, wire bead, 60 tpi, 27.5x2.40" / Sizes M, L and XL: Bontrager Gunnison Elite XR, Tubeless Ready, wire bead, 60 tpi, 29x2.40"
Rim strip: Bontrager TLR
Maximum tyre size: See service manual
Cockpit
Handlebar: Bontrager Comp, alloy, 31.8 mm, 40 mm rise, 780 mm width
Grips: Bontrager XR Endurance Comp, lock-on
Stem: Bontrager Rhythm Comp, 31.8 mm, 0-degree, 50 mm length
Headset: FSA IS-2, 1-1/8" top, 1.5" bottom
Additional Features
Saddle: Bontrager Commuter Comp
Seatpost: Size S: TranzX JD-YSI34, 100 mm travel, internal routing, 31.6 mm, 350 mm length / Size M: TranzX JD-YSI34, 150 mm travel, internal routing, 31.6 mm, 456 mm length / Sizes L and XL: TranzX JD-YSI34, 170 mm travel, internal routing, 31.6 mm, 500 mm length
Weight
Weight: Size M – 24.10 kg / 53.14 lbs
Weight limit: This bike has a maximum total weight limit, including the bicycle, rider and cargo, of 136 kg / 300 lbs.
Care Instructions
We reserve the right to make changes to the product information at any time without notice, including equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted without notice.
Bike and frame weights are based on pre-production painted frames at the time of publication. Final production weights may vary.
