Please note – spec applies to all sizes unless listed separately.
Frameset
Frame: Alpha Platinum Aluminium, Removable Integrated Battery (RIB 2.0), tapered head tube, guided internal routing, Control Freak internal routing, Motor Armour, Boost148, 12 mm thru axle
Fork: Size S: Fox AWL Rail, Rail 2.0 damper, tapered steerer, 44 mm offset, Boost110, 15 mm Kabolt axle, 180 mm direct mount, 100 mm travel, 27.5" / Sizes M, L and XL: Fox AWL Rail, Rail 2.0 damper, tapered steerer, 44 mm offset, Boost110, 15 mm Kabolt axle, 180 mm direct mount, 120 mm travel, 29"
E-system
Computer: Sizes S, M, L and XL: Bosch Kiox 300, smart system and Bosch LED remote, smart system
Motor: Bosch Performance Line CX, Europe and APAC: 25 km/h, US and rest of world: 20 mph / 32 km/h
E-bike classification: Class 1
Drivetrain and brakes
Shifter: SRAM Eagle 70, 12-speed
Rear derailleur: SRAM Eagle 70, T-Type
Crank: FSA alloy, 160 mm length
Cassette: SRAM Eagle XS-1270, T-Type, 10-52, 12-speed
Chain: SRAM Eagle 70, T-Type, 12-speed
Pedals: VP-536 nylon platform
Maximum chainring size: 1x: 42T
Brakes: Shimano BR-MT620 hydraulic disc
Brake rotors: Shimano RT64, CentreLock, 203 mm
Maximum brake rotor size: Frame: 203 mm / Fork: see fork manufacturer
Wheels and tyres
Front hub: Shimano TC500 alloy, CentreLock, 110x15 mm thru axle
Rear hub: Shimano TC500 alloy, CentreLock, 148x12 mm thru axle
Rear skewer: Bontrager Switch thru axle, removable lever
Rims: Sizes S, M, L and XL: Bontrager Kovee, double-wall, Tubeless Ready, 23 mm width, Presta valve, 28-hole or 32-hole
Spokes: 14 g stainless steel, black
Tyres: Size S: Bontrager Gunnison Pro XR, Tubeless Ready, wire bead, 60 tpi, 27.5x2.40" / Sizes M, L and XL: Bontrager Gunnison Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 29x2.40"
Tyre sealant: Bontrager TLR sealant, 180 ml / 6 oz
Rim strip: Bontrager TLR
Maximum tyre size: See service manual
Cockpit
Handlebar: Bontrager Comp, alloy, 31.8 mm, 40 mm rise, 780 mm width
Grips: Bontrager XR Endurance Elite
Stem: Bontrager Rhythm Comp, 31.8 mm, 0-degree, 50 mm length
Headset: FSA IS-2, 1-1/8" top, 1.5" bottom
Additional Features
Saddle: Bontrager Commuter Comp
Seatpost: Size S: Bontrager Line Dropper, 100 mm travel, MaxFlow, internal routing, 31.6 mm, 310 mm length / Sizes M, L and XL: Bontrager Line Dropper, 170 mm travel, MaxFlow, internal routing, 31.6 mm, 450 mm length
Tool: Bontrager Switch thru axle, removable lever
Weight
Weight: Size M – 23.08 kg / 50.89 lbs
Weight limit: This bike has a maximum total weight limit, including the bicycle, rider and cargo, of 136 kg / 300 lbs.
Care Instructions
We reserve the right to make changes to the product information at any time without notice, including equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted without notice.
Bike and frame weights are based on pre-production painted frames at the time of publication. Final production weights may vary.
