Please note – spec applies to all sizes unless listed separately.
Frameset
Frame: Alpha Platinum Aluminium, Removable Integrated Battery (RIB 2.0), tapered headtube, guided internal routing, Motor Armor, Mino Link adjustable geometry, adjustable leverage rate, 34.9 mm seat tube, ABP, UDH, rack and mudguard mounts, Boost148, 120 mm travel
Fork: Fox Rhythm 36, Float EVOL air spring, GRIP damper, tapered steerer, 44 mm offset, Boost110, 15 mm Kabolt axle, 150 mm travel
Shock: Fox Float Rhythm, 2-position damper, 210x50 mm
E-system
Motor: Bosch Performance Line CX, Europe and APAC: 25 km/h, US and rest of world: 20 mph / 32 km/h
Battery: Bosch PowerTube 800 Wh, smart system
Charger: Bosch standard 4A, 230V, smart system
Computer: Sizes S, M, L and XL: Bosch Kiox 300, smart system and Bosch LED remote, smart system
Drivetrain and brakes
Shifter: Shimano XT Di2 M8250, 12-speed
Rear derailleur: Shimano XT Di2 M8260, 12-speed
Crank arms: E*thirteen E*spec Plus, 160 mm length
Cassette: Shimano XT M8100, 10-51, 12-speed
Chain: Shimano Deore M6100, 12-speed
Pedals: VP-536 nylon platform
Maximum chainring size: 1x: 38T
Brakes: Shimano XT M8220, 4-piston hydraulic disc
Brake rotors: Shimano RT-6B750, 6-bolt, 200 mm
Brake rotor size: Frame: maximum 220 mm, minimum 180 mm / Fork: see fork manufacturer
Wheels and tyres
Front hub: Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Boost110, 15 mm thru axle
Rear hub: Bontrager alloy, sealed bearing, 6-bolt, Rapid Drive 108, Shimano freehub, Boost148, 12 mm thru axle
Rear skewer: Bontrager Switch thru axle, removable lever
Spokes: Sizes S, M, L and XL: 14 g stainless steel, black
Tyres: Size S: Bontrager Gunnison Pro XR, Tubeless Ready, wire bead, 60 tpi, 27.5x2.40" / Sizes M, L and XL: Bontrager Gunnison Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 29x2.40"
Tyre sealant: Bontrager TLR sealant, 180 ml / 6 oz
Rim strip: Bontrager TLR
Maximum tyre size: Frame: 29x2.50", size S: 27.5x2.50" / Fork: see manufacturer
Cockpit
Handlebar: Bontrager Comp, alloy, 31.8 mm, 40 mm rise, 780 mm width
Grips: Trek Line Comp, nylon lock-on
Stem: Bontrager Rhythm Comp, 31.8 mm, 0-degree, 50 mm length
Headset: FSA IS-2, 1-1/8" top, 1.5" bottom
Additional Features
Saddle: Bontrager Verse P3, steel rails
Seatpost: Size S: Bontrager Line Dropper, 100 mm travel, MaxFlow, internal routing, 31.6 mm, 310 mm length / Sizes M, L and XL: Bontrager Line Dropper, 170 mm travel, MaxFlow, internal routing, 31.6 mm, 450 mm length
Mudguard: Trek custom mudguard
Weight
Weight: Size M – 24.88 kg / 54.86 lbs, with TLR sealant and no tubes
Weight limit: This bike has a maximum total weight limit, including the bicycle, rider and cargo, of 136 kg / 300 lbs.
Care Instructions
We reserve the right to make changes to the product information at any time without notice, including equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted without notice.
Bike and frame weights are based on pre-production painted frames at the time of publication. Final production weights may vary.
