Please note – spec applies to all sizes unless listed separately.
Frameset
Frame: Alpha Platinum Aluminium, Removable Integrated Battery (RIB 2.0), tapered headtube, guided internal routing, Motor Armor, Mino Link adjustable geometry, adjustable leverage rate, 34.9 mm seat tube, ABP, UDH, rack and mudguard mounts, Boost148, 120 mm travel
Fork: RockShox Recon Silver, Solo Air spring, Motion Control damper, lockout, tapered steerer, 42 mm offset, Boost110, Maxle Stealth, mudguard mounts, 130 mm travel
Shock: RockShox Deluxe Select, 210x50 mm
E-system
Battery: Bosch PowerTube 800 Wh, smart system
Charger: Bosch standard 2A, 230V, smart system
E-bike classification: Class 1
Drivetrain and brakes
Shifter: Shimano U6000, 10-speed
Rear derailleur: Shimano CUES U6000 GS
Crank: FSA Bosch CK-220, 36T ring, 165 mm length
Chainring: FSA, 36T, steel
Cassette: Shimano CUES LG300, LINKGLIDE, 11-48, 10-speed
Chain: Shimano LG500, 9/10/11-speed
Pedals: VP-536 nylon platform
Maximum chainring size: 1x: 38T
Brakes: Tektro HD-M5140 hydraulic disc
Brake rotors: Tektro, CentreLock, 203 mm
Brake rotor size: Frame: maximum 220 mm, minimum 180 mm / Fork: see fork manufacturer
Wheels and tyres
Front hub: Shimano TC500 alloy, CentreLock, 110x15 mm thru axle
Rear hub: Shimano TC500 alloy, CentreLock, 148x12 mm thru axle
Rims: Sizes S, M, L and XL: Bontrager Kovee, double-wall, Tubeless Ready, 23 mm width, Presta valve, 28-hole or 32-hole
Spokes: 14 g stainless steel, black
Tyres: Size S: Bontrager Gunnison Elite XR, Tubeless Ready, wire bead, 60 tpi, 27.5x2.40" / Sizes M, L and XL: Bontrager Gunnison Elite XR, Tubeless Ready, wire bead, 60 tpi, 29x2.40"
Maximum tyre size: Frame: 29x2.50", size S: 27.5x2.50" / Fork: see manufacturer
Cockpit
Handlebar: Bontrager Comp, alloy, 31.8 mm, 40 mm rise, 780 mm width
Grips: Trek Line Comp, nylon lock-on
Stem: Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length
Headset: FSA IS-2, 1-1/8" top, 1.5" bottom
Additional Features
Saddle: Bontrager Verse P3, steel rails
Seatpost: Size S: TranzX JD-YSI34, 100 mm travel, internal routing, 31.6 mm, 350 mm length / Size M: TranzX JD-YSI34, 150 mm travel, internal routing, 31.6 mm, 456 mm length / Sizes L and XL: TranzX JD-YSI34, 170 mm travel, internal routing, 31.6 mm, 500 mm length
Weight
Weight: Size M – 25.50 kg / 56.22 lbs
Weight limit: This bike has a maximum total weight limit, including the bicycle, rider and cargo, of 136 kg / 300 lbs.
Care Instructions
We reserve the right to make changes to the product information at any time without notice, including equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted without notice.
Bike and frame weights are based on pre-production painted frames at the time of publication. Final production weights may vary.
