Please note – spec applies to all sizes unless listed separately.
Frameset
Frame: Alpha Platinum Aluminium, Removable Integrated Battery (RIB 2.0), tapered head tube, guided internal routing, Control Freak internal routing, Motor Armour, Boost148, 12 mm thru axle
Fork: SR Suntour XCM 34, air spring, lockout, rebound adjuster, tapered steerer, Boost110, 15 mm thru axle, 120 mm travel
E-system
Motor: Bosch Performance Line CX, Europe and APAC: 25 km/h, US and rest of world: 20 mph / 32 km/h
Battery: Bosch PowerTube 800 Wh, smart system
Charger: Bosch standard 2A, 230V, smart system
Computer: Bosch Purion 200
E-bike classification: Class 1
Drivetrain and brakes
Shifter: Shimano U6000, 10-speed
Rear derailleur: Shimano CUES U6000 GS
Crank: FSA Bosch CK-220, 36T ring, 165 mm length
Chainring: FSA, 36T, steel
Cassette: Shimano CUES LG300, LINKGLIDE, 11-48, 10-speed
Chain: Shimano LG500, 9/10/11-speed
Pedals: VP-536 nylon platform
Maximum chainring size: 1x: 42T
Brake rotors: Tektro, CentreLock, 203 mm
Maximum brake rotor size: Frame: 203 mm / Fork: see fork manufacturer
Wheels and tyres
Front hub: Shimano TC500 alloy, CentreLock, 110x15 mm thru axle
Rear hub: Shimano TC500 alloy, CentreLock, 148x12 mm thru axle
Rear skewer: Bontrager Switch thru axle, removable lever
Rims: Bontrager Connection, double-wall, 32-hole, 20 mm width, Presta valve
Spokes: 14 g stainless steel, black
Tyres: Size S: Bontrager Connection Elite, reflective strip, wire bead, 60 tpi, 27.5x2.40" / Sizes M, L and XL: Bontrager Connection Elite, reflective strip, wire bead, 60 tpi, 29x2.40"
Maximum tyre size: See service manual
Cockpit
Handlebar: Bontrager Comp, alloy, 31.8 mm, 40 mm rise, 780 mm width
Grips: Bontrager XR Endurance Comp, lock-on
Stem: Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length
Headset: FSA IS-2, 1-1/8" top, 1.5" bottom
Additional Features
Saddle: Bontrager Commuter Comp
Seatpost: Size S: Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length / Size M: Bontrager alloy, 31.6 mm, 12 mm offset, 360 mm length / Sizes L and XL: Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length
Lights: Sizes S, M, L and XL: Supernova Mini 3 Pure LED headlight and Supernova TL3 Mini LED rear light
Kickstand: Pletscher Comp Flex 18
Cargo rack: MIK-compatible alloy rear rack
Mudguards: Size S: Trek Powerfly 27.5" custom mudguard / Sizes M, L and XL: Trek Powerfly 29" custom mudguard
Weight
Weight: Size M – 27.20 kg / 59.97 lbs
Weight limit: This bike has a maximum total weight limit, including the bicycle, rider and cargo, of 136 kg / 300 lbs.
Care Instructions
We reserve the right to make changes to the product information at any time without notice, including equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted without notice.
Bike and frame weights are based on pre-production painted frames at the time of publication. Final production weights may vary.
