*Please note – spec applies to all sizes unless listed separately
Frameset
Frame: Alpha Platinum Aluminium, Removable Integrated Battery (RIB 2.0), tapered head tube, guided internal routing, Control Freak internal routing, Motor Armour, Boost148, 12 mm thru axle
Fork:
- S: SR Suntour XCR 34, air spring, 2CR damper, hydraulic lockout, tapered steerer, 44 mm offset, Boost 110, 15 mm bolt-on thru axle, 100 mm travel
- M, L, XL: SR Suntour XCR 34, air spring, 2CR damper, hydraulic lockout, tapered steerer, 44 mm offset, Boost 110, 15 mm bolt-on thru axle, 120 mm travel
Max compatible fork travel: See service manual
Wheels
Hub front: Shimano TC500 alloy, CentreLock, 110x15 mm thru axle
Hub rear: Shimano TC500 alloy, CentreLock, 148x12 mm thru axle
Skewer rear: Bontrager Switch thru axle, removable lever
Rim: Bontrager Connection, double-wall, 32-hole, 20 mm width, Presta valve
Max tyre size: Frame: 29x2.50" (S: 27.5x2.50"), Fork: see manufacturer
E-system
Battery: Bosch PowerTube 800 Wh, smart system
Computer: Bosch Purion 200
Motor: Bosch Performance Line CX, 20 mph / 32 km/h max assist (25 km/h max assist in EU and APAC)
Drivetrain
Shifter: Shimano U6000, 10-speed
Rear derailleur: Shimano CUES U6000 GS
Crank: FSA Bosch CK-220, 36T ring, 165 mm length
Chainring: FSA, 36T, steel
Cassette: Shimano CUES LG300, LINKGLIDE, 11-48, 10-speed
Chain: Shimano LG500, 9/10/11-speed
Pedal: VP-536 nylon platform
Max. chainring size: 1x: 38T
Components
Saddle: Bontrager Commuter Comp
Seatpost:
- S: Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length
- M: Bontrager alloy, 31.6 mm, 12 mm offset, 360 mm length
- L, XL: Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length
Handlebar: Bontrager Comp, alloy, 31.8 mm, 40mm rise, 780 mm width
Grips:
- S, M, L, XL: Bontrager XR Endurance Comp, lock-on
- S, M, L, XL: Trek Line Ergonomic Comp, lock-on
Stem: Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length
Headset: FSA IS-2, 1-1/8" top, 1.5" bottom
Brakes
Brake Set: Tektro HD-M275 hydraulic disc
Brake rotor: Tektro, CentreLock, 203 mm
Rotor size: Max brake rotor sizes – Frame: 220 mm, min 180 mm, Fork: see fork manufacturer
Accessories
Tool: Bontrager Switch Lever, w/tool
Weight
Weight limit: This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb)
We reserve the right to make changes to the product information contained on this site at any time without notice, including equipment, specifications, models, colours, materials and pricing. Compatible parts may be substituted due to supply chain issues. Bike and frame weights are based on pre-production painted frames at time of publication; weights may vary in final production.
