Please note – spec applies to all sizes unless listed separately.
Frameset
Frame: OCLV Mountain Carbon, IsoBow, tapered head tube, guided internal routing, rack and accessory mounts, balanced post mount brake, UDH, Boost148
Fork: Sizes S, M, ML, L and XL: RockShox Reba RL, DebonAir, Motion Control damper, lockout, tapered steerer, 44 mm offset, Boost110, 15 mm Maxle Stealth, 120 mm travel or Fox Factory 34, Float EVOL air spring, GRIP2 damper, tapered steerer, 44 mm offset, Kashima Coat, Boost110, 15 mm Kabolt axle, 130 mm travel
Suspension part: Bontrager Drop Lock remote
Wheels and tyres
Front wheel: Bontrager Kovee Comp 25, Tubeless Ready, 6-bolt, Boost110, 15 mm thru axle, 29"
Rear wheel: Bontrager Kovee Comp 25, Tubeless Ready, Rapid Drive 108, Boost148, 12 mm thru axle, 29"
Rear skewer: Bontrager Switch thru axle, removable lever
Tyres: Bontrager Sainte-Anne Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 29x2.40"
Tyre sealant: Bontrager TLR sealant, 180 ml / 6 oz
Rim strip: Bontrager TLR
Maximum tyre size: Frame: 29x2.40" / Fork: see manufacturer
Drivetrain and brakes
Shifter: SRAM Eagle 70, 12-speed
Rear derailleur: SRAM Eagle 70, T-Type
Crank: Size S, M, ML: SRAM Eagle 70, T-Type, DUB, 32T, 55 mm chainline, 170 mm length / Size L, XL: SRAM Eagle 70, T-Type, DUB, 32T, 55 mm chainline, 175 mm length
Bottom bracket: SRAM DUB, 92 mm, PressFit
Cassette: SRAM Eagle XS-1270, T-Type, 10-52, 12-speed
Chain: SRAM Eagle 70, T-Type, 12-speed
Maximum chainring size: 1x: 38T
Brake rotors: Sizes S, M, ML, L and XL: SRAM CentreLine, 6-bolt, round-edge, 180 mm, SRAM CenterLine, 6-bolt, round-edge, 160 mm or SRAM CenterLine 2.0, 6-bolt, 180 mm
Maximum brake rotor size: Frame: 180 mm / Fork: see fork manufacturer
Cockpit
Handlebar: Size S: Bontrager Comp, alloy, 31.8 mm, 5 mm rise, 720 mm width / Size M, ML, L, XL: Bontrager Rhythm Comp, alloy, 31.8 mm, 15 mm rise, 750 mm width
Grips: Trek Line Comp, nylon lock-on
Stem: Size S: Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length / Size M, ML: Bontrager Elite, 31.8 mm, Blendr compatible, 7-degree, 60 mm length / Size L: Bontrager Elite, 31.8 mm, Blendr compatible, 7-degree, 70 mm length / Size XL: Bontrager Elite, 31.8 mm, Blendr compatible, 7-degree, 80 mm length
Headset: FSA IS-2, 1-1/8" top, 1.5" bottom
Additional Features
Saddle: Sizes S, M, ML, L and XL: Verse Short Comp, steel rails, 145 mm width or Bontrager Arvada Pro, carbon rails, 138 mm width
Seatpost: Size S: Bontrager Line Dropper, 100 mm travel, MaxFlow, internal routing, 31.6 mm, 310 mm length / Size M, ML, L: Bontrager Line Dropper, 150 mm travel, MaxFlow, internal routing, 31.6 mm, 410 mm length / Size XL: Bontrager Line Dropper, 170 mm travel, MaxFlow, internal routing, 31.6 mm, 450 mm length or Bontrager Line Elite Dropper, 170 mm travel, MaxFlow, internal routing, 31.6 mm, 480 mm length
Tool: Bontrager Switch thru axle, removable lever
Weight
Weight: Size M – 11.83 kg / 26.09 lb, with TLR sealant and no tubes
Weight limit: This bike has a maximum total weight limit, including the bicycle, rider and cargo, of 136 kg / 300 lb.
Care Instructions
We reserve the right to make changes to the product information at any time without notice, including equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted without notice.
Bike and frame weights are based on pre-production painted frames at the time of publication. Final production weights may vary.
