*Please note – spec applies to all sizes unless listed separately
Frameset
Frame:
Alpha Platinum, Removable Integrated Battery (RIB 2.0), tapered headtube, internal routing, Motor Armour, rack and mudguard mounts, ABP, Boost 148, 120 mm travel
Shock: RockShox Deluxe Select R, 210x50 mm
Max compatible fork travel: See service manual
Wheels
Hub (front): Shimano TC500 alloy, CentreLock, 110x15 mm thru axle
Hub (rear): Shimano TC500 alloy, CentreLock, 148x12 mm thru axle
Skewer rear: Bontrager Switch thru-axle, removable lever
Rim:
Size: S, M, L, XL – Bontrager Line TLR 30, Tubeless-Ready, 28-hole, Presta valve
Size: S, M, L, XL – Bontrager Line TLR 30, Tubeless-Ready, 32-hole, Presta valve
Spokes:
Size: S, M, L, XL – 14g stainless
Size: M, L, XL – 14 g stainless steel, black
Tyre:
Size: S – Bontrager Gunnison Pro XR, Tubeless-Ready, wire bead, 60 tpi, 27.5x2.40"
Size: M, L, XL – Bontrager Gunnison Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 29x2.40"
Tyre part: Bontrager TLR sealant, 180 ml/6 oz
Rim strip: Bontrager TLR
Max tyre size: Frame: 29x2.50" (S: 27.5x2.50"), Fork: see manufacturer
E-system
Computer: Bosch Purion 200
Motor: Bosch Performance Line CX, 20 mph (25 km/h in Europe)
Drivetrain
Shifter: Shimano U6000, 10-speed
Rear derailleur: Shimano CUES U6000 GS
Crank: FSA Bosch CK-220, 36T ring, 165 mm length
Chainring: FSA, 36T, steel<b
