<div style="font-family: Arial, sans-serif; text-align:left;">
<p><em>*Please note – spec applies to all sizes unless listed separately</em></p>
<h2 style="color:#4587c6;">Frameset</h2>
<p>
<strong>Frame:</strong> Alpha Platinum Aluminium, Removable Integrated Battery (RIB 2.0), tapered head tube, guided internal routing, Control Freak internal routing, Motor Armour, Boost148, 12 mm thru axle<br>
<strong>Fork:</strong>
<ul>
<li>S: SR Suntour XCR 34, air spring, 2CR damper, hydraulic lockout, tapered steerer, 44 mm offset, Boost 110, 15 mm bolt-on thru axle, 100 mm travel</li>
<li>M, L, XL: SR Suntour XCR 34, air spring, 2CR damper, hydraulic lockout, tapered steerer, 44 mm offset, Boost 110, 15 mm bolt-on thru axle, 120 mm travel</li>
</ul>
<strong>Max compatible fork travel:</strong> See service manual
</p>
<hr>
<h2 style="color:#4587c6;">Wheels</h2>
<p>
<strong>Hub front:</strong> Shimano TC500 alloy, CentreLock, 110x15 mm thru axle<br>
<strong>Hub rear:</strong> Shimano TC500 alloy, CentreLock, 148x12 mm thru axle<br>
<strong>Skewer rear:</strong> Bontrager Switch thru axle, removable lever<br>
<strong>Rim:</strong> Bontrager Connection, double-wall, 32-hole, 20 mm width, Presta valve<br>
<strong>Tyre:</strong>
<ul>
<li>S: Bontrager LT4 Expert, reflective strip, wire bead, 60 tpi, 27.5x2.40"</li>
<li>M, L, XL: Bontrager LT4 Expert, reflective strip, wire bead, 60 tpi, 29x2.40"</li>
</ul>
<strong>Max tyre size:</strong> See service manual
</p>
<hr>
<h2 style="color:#4587c6;">E-system</h2>
<p>
<strong>Battery:</strong> Bosch PowerTube 600 Wh, smart system<br>
<strong>Charger:</strong> Bosch standard 2A, 230V, smart system<br>
<strong>Computer:</strong> Bosch Purion 200<br>
<strong>Motor:</strong> Bosch Performance Line CX, 20 mph (25 km/h in Europe)
</p>
<hr>
<h2 style="color:#4587c6;">Drivetrain</h2>
<p>
<strong>Shifter:</strong> Shimano U6000, 10-speed<br>
<strong>Rear derailleur:</strong> Shimano CUES U6000 GS<br>
<strong>Crank:</strong> FSA Bosch CK-220, 36T ring, 165 mm length<br>
<strong>Cassette:</strong> Shimano CUES LG300, LINKGLIDE, 11-48, 10-speed<br>
<strong>Chain:</strong> Shimano LG500, 9/10/11-speed<br>
<strong>Pedal:</strong> VP-536 nylon platform<br>
<strong>Max. chainring size:</strong> 1x: 42T
</p>
<hr>
<h2 style="color:#4587c6;">Components</h2>
<p>
<strong>Saddle:</strong> Bontrager Commuter Comp<br>
<strong>Seatpost:</strong>
<ul>
<li>S: Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length</li>
<li>M: Bontrager alloy, 31.6 mm, 12 mm offset, 360 mm length</li>
<li>L, XL: Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length</li>
</ul>
<strong>Handlebar:</strong> Bontrager Comp, alloy, 31.8 mm, 40mm rise, 780 mm width<br>
<strong>Grips:</strong> Bontrager XR Endurance Comp, lock-on<br>
<strong>Stem:</strong> Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length<br>
<strong>Headset:</strong> FSA IS-2, 1-1/8" top, 1.5" bottom
</p>
<hr>
<h2 style="color:#4587c6;">Brakes</h2>
<p>
<strong>Brake Set:</strong> Tektro HD-M275 hydraulic disc<br>
<strong>Brake rotor:</strong> Tektro, CentreLock, 203 mm<br>
<strong>Rotor size:</strong> Max brake rotor sizes – Frame: 203 mm, min 180 mm, fork: see fork manufacturer
</p>
<hr>
<h2 style="color:#4587c6;">Accessories</h2>
<p>
<strong>Light:</strong>
<ul>
<li>S, M, L, XL: Supernova Mini 3 pure, LED, headlight</li>
<li>S, M, L, XL: Supernova TL3 Mini, LED</li>
</ul>
<strong>Kickstand:</strong> Pletscher Comp Flex 18<br>
<strong>Cargo rack:</strong> MIK-compatible alloy rear rack<br>
<strong>Mudguard:</strong>
<ul>
<li>S: Trek Powerfly 27.5" custom fender</li>
<li>M, L, XL: Trek Powerfly 29" custom fender</li>
</ul>
<strong>Tool:</strong> Bontrager Switch Lever, w/tool
</p>
<hr>
<h2 style="color:#4587c6;">Weight</h2>
<p>
<strong>Weight limit:</strong> This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb)
</p>
</div>
