*Please note – spec applies to all sizes unless listed separately
Frameset
Frame: Size: S, XL, L, M – Alpha NEXT Platinum aluminium, internal storage, ZS headset, adjustable leverage rate, guided internal routing, interchangeable alloy rocker link, interchangeable lower shock mount, downtube guard, shuttle guard, BSA 73, ISCG 05, ABP, UDH, Boost148, adaptable travel 145 mm-160 mm
Fork: Size: S, XL, L, M – Fox Factory 38, Float EVOL air spring, GRIP X2 damper, 44 mm offset, Boost110, 15 mm Kabolt X axle, 170 mm travel
Shock: Size: S, XL, L, M – Fox DHX2, 205 mm x 65 mm
Suspension Part: Size: S – Fox steel coil spring, 250 lbs
Size: M – Fox steel coil spring, 350 lbs
Size: L – Fox steel coil spring, 400 lbs
Size: XL – Fox steel coil spring, 450 lbs
Wheels
Front Wheel: Size: S, XL, L, M – Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15 mm thru-axle, 29"
Rear Wheel: Size: S, XL, L, M – Bontrager Line Comp 30, Tubeless-Ready, Rapid Drive 108, 6-bolt, SRAM XD freehub, Boost148, 12 mm thru-axle, 29"
Rear Skewer: Size: S, XL, L, M – Bontrager Switch thru-axle, removable lever
Tire: Size: S, XL, L, M – Maxxis Assegai, tubeless-ready, 3C, EXO+ casing, MAXXGRIP, folding bead, 29x2.5"
Size: S, XL, L, M – Maxxis Minion DHR II, tubeless-ready, 3C, EXO+ casing, MAXXTERRA, folding bead, 29x2.5"
Tire Part: Size: S, XL, L, M – Bontrager TLR sealant, 180 ml/6 oz
Max tyre size: Frame: 29x2.50", Fork: See manufacturer
Drivetrain
Shifter: Size: S, XL, L, M – SRAM Eagle 90, 12-speed
Rear Derailleur: Size: S, XL, L, M – SRAM Eagle 90, T-Type
Crank: Size: S, XL, L, M – SRAM Eagle 90, DUB, 30T steel, T-Type, 55 mm chainline, 170 mm length
Bottom Bracket: Size: S, XL, L, M – SRAM DUB MTB Wide, 73 mm, BSA threaded
Cassette: Size: S, XL, L, M – SRAM Eagle XS-1275, T-Type, 10-52, 12-speed
Chain: Size: S, XL, L, M – SRAM GX Eagle, T-Type, 12-speed
Max. chainring size: Max: 34T (oval – 32T) Min: 30T (oval – 32T)
Components
Saddle: Size: S, XL, L, M – Verse Short Comp, steel rails, 145 mm width
Seatpost: Size: S – Bontrager Line Dropper, 150 mm travel, MaxFlow, internal routing, 34.9 mm, 410 mm length
Size: M – Bontrager Line Dropper, 170 mm travel, MaxFlow, internal routing, 34.9 mm, 450 mm length
Size: XL, L – Bontrager Line Dropper, 200 mm travel, MaxFlow, internal routing, 34.9 mm, 515 mm length
Handlebar: Size: S, XL, L, M – Race Face Turbine, alloy, 35 mm, 40 mm rise, 780 mm width
Grips: Size: S, XL, L – Trek Line Elite, lock-on
Stem: Size: S, XL, L, M – Bontrager Elite, 35 mm, 0-degree, 45 mm length
Brakes
Brake: Size: S, XL, L, M – SRAM Maven Bronze, 4-piston hydraulic disc
Brake Rotor: Size: S, XL, L, M – SRAM HS2, 6-bolt, 180 mm / 200 mm
Rotor size: Max brake rotor sizes – Frame: 203 mm, min 180 mm, Fork: see fork manufacturer
Weight
Weight: M – 17.38 kg / 38.32 lbs (with TLR sealant, no tubes)
Weight limit: 136 kg (300 lb)
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
