*Please note – spec applies to all sizes unless listed separately
Frameset
Mainframe: Size: S, XL, L, M – Alpha NEXT Platinum aluminium, removable battery, ZS headset, adjustable leverage rate, guided internal routing, interchangeable alloy rocker link, interchangeable lower shock mount, downtube guard, shuttle guard, ABP, UDH, Boost148, adaptable travel 145 mm-160 mm
Fork: Size: S, XL, L, M – Rockshox Recon Silver RL, Solo Air spring, Motion Control damper, lockout, tapered steerer, 42 offset, Boost110, 15 mm Maxle Stealth, 150 mm travel
Shock: Size: S, XL, L, M – X-Fusion Pro 2, 2-position damper, 205 mm x 60mm
Wheels
Front Hub: Size: S, XL, L, M – Shimano TC500 alloy, CentreLock, 110x15 mm thru axle
Rear Hub: Size: S, XL, L, M – Shimano TC500 alloy, CentreLock, 148x12 mm thru axle
Rear Skewer: Size: S, XL, L, M – Bontrager Switch thru-axle, removable lever
Rim: Size: S, XL, L, M – Bontrager Line TLR 30, Tubeless-Ready, 32-hole, Presta valve / 28-hole, Presta valve
Spokes: Size: S, XL, L, M – 14 g stainless steel, black
Tire: Size: S – Bontrager Gunnison Elite XR, Tubeless Ready, wire bead, 60 tpi, 27.5x2.40"
Size: S, XL, L, M – Bontrager Gunnison Elite XR, Tubeless Ready, wire bead, 60 tpi, 29x2.40"
Tire Part: Size: S, XL, L, M – Bontrager TLR sealant, 180 ml/6 oz
Rim Strip: Size: S, XL, L, M – Bontrager TLR
Max tyre size: Frame: 29x2.50", Fork: See manufacturer
E-system
Battery: Size: S, XL, L, M – TQ 580Wh
Charger: Size: S
