Please note – spec applies to all sizes unless listed separately.
Frameset
Frame: 500 Series OCLV Carbon, TQ drive system, tapered head tube, integrated frame bag mounts, flat-mount disc, mudguard mounts, UDH, 142x12 mm chamfered thru axle
Fork: Domane+ carbon, tapered carbon steerer, internal brake routing, mudguard mounts, flat-mount disc, 12x100 mm chamfered thru axle
E-system
Motor: TQ-HPR40, 40 Nm, 200 watt peak power
Battery: TQ 360 Wh
Charger: TQ 4A charger
Controller: TQ colour LED display with Bluetooth and ANT+ connectivity
Maximum assist speed: 15.5 mph
Drivetrain and brakes
Shifter: SRAM RED AXS E1
Rear derailleur: SRAM RED XPLR eTap AXS, 46T max cog
Crank arms: Sizes XS, S, M and ML: E*thirteen Piedmont Race Carbon E*spec, 165 mm length / Sizes L and XL: E*thirteen Piedmont Race Carbon E*spec, 170 mm length
Chainring: SRAM X-SYNC, 44T, alloy
Cassette: SRAM XG-1391, 10-46T, 13-speed
Chain: SRAM RED E1, 12/13-speed
Maximum chainring size: 1x: 48T
Brake rotors: SRAM Paceline X, rounded, CentreLock, 160 mm
Maximum brake rotor size: 160 mm front and rear
Wheels and tyres
Front wheel: Bontrager Aeolus RSL 37, OCLV Carbon, Tubeless Ready, 37 mm rim depth, 100x12 mm thru axle
Rear wheel: Bontrager Aeolus RSL 37, OCLV Carbon, Tubeless Ready, 37 mm rim depth, 142x12 mm thru axle
Front skewer: Bontrager Switch chamfered thru axle
Rear skewer: Bontrager Switch chamfered thru axle, removable lever
Tyres: Bontrager Kwaremont RSL, Tubeless Ready, GR puncture protection, aramid bead, 320 tpi, 700x35 mm
Rim strip: Bontrager TLR
Tubes: Pirelli P Zero SmarTube, TPU
Maximum tyre size: 40 mm without mudguards / 35 mm with mudguards
Cockpit
Handlebar: Size XS: Bontrager Pro Riser, carbon, 20 mm rise, 31.8 mm clamp, 70 mm reach, 36 cm width / Size S: Bontrager Pro Riser, carbon, 20 mm rise, 31.8 mm clamp, 70 mm reach, 38 cm width / Sizes M and ML: Bontrager Pro Riser, carbon, 20 mm rise, 31.8 mm clamp, 70 mm reach, 40 cm width / Sizes L and XL: Bontrager Pro Riser, carbon, 20 mm rise, 31.8 mm clamp, 70 mm reach, 42 cm width
Handlebar tape: Trek gel cork
Stem: Size XS: Trek RCS Pro, -7-degree, 80 mm length / Size S: Trek RCS Pro, -7-degree, 90 mm length / Size M: Trek RCS Pro, -7-degree, 100 mm length / Sizes ML and L: Trek RCS Pro, -7-degree, 110 mm length / Size XL: Trek RCS Pro, -7-degree, 120 mm length
Additional Features
Saddle: Verse Short Pro, carbon rails, 145 mm width
Seatpost: Bontrager RSL carbon, 27.2 mm, 5 mm offset
Lights: Sizes XS, S, M, ML, L and XL: Trek Flare C taillight and SUPERNOVA SS Mini headlight
Weight
Weight: Size ML – 11.00 kg / 24.26 lb, with TLR sealant and no tubes
Weight limit: This bike has a maximum total weight limit, including the bicycle, rider and cargo, of 125 kg / 275 lb.
We reserve the right to make changes to the product information at any time without notice, including equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted without notice.
Bike and frame weights are based on pre-production painted frames at the time of publication. Final production weights may vary.
