*Please note – spec applies to all sizes unless listed separately
Frameset
Frame with Fork: 900 Series OCLV Carbon, Full System Foil tube shaping, IsoFlow seat tube, RCS Headset System, electronic-only routing, removable aero chain keeper, T47 BB, flat mount disc, UDH, 142x12 mm thru axle
Fork: Madone Gen 8 one-piece carbon, tapered carbon steerer, internal brake routing, flat mount disc, 12x100 mm chamfered thru axle
Weight
Weight: ML – 7.00 kg / 15.44 lb (with TLR sealant, no tubes, no bottles/cages)
Weight limit: 125 kg (275 lb)
E-system
Battery: SRAM AXS battery pack (with charger)
Drivetrain
Shifter: SRAM RED AXS E1
Front derailleur: SRAM RED AXS E1, braze-on
Rear derailleur: SRAM RED AXS E1, 36T max cog
Crank:
Size: XS, S – SRAM RED AXS E1, power meter, 48/35, DUB, 165 mm length
Size: L, M, ML – SRAM RED AXS E1, power meter, 48/35, DUB, 170 mm length
Size: XL, L – SRAM RED AXS E1, power meter, 48/35, DUB, 172.5 mm length
Bottom bracket: SRAM DUB, T47 threaded, internal bearing
Cassette: SRAM RED XG-1290 E1, 10-33, 12-speed
Chain: SRAM RED E1, 12-speed
Max. chainring size: 1x: 54T, 2x: 56/43
Wheels
Front wheel: Bontrager Aeolus RSL 51, OCLV Carbon, Tubeless Ready, 51 mm rim depth, 100x12 mm thru axle
Rear wheel: Bontrager Aeolus RSL 51, OCLV Carbon, Tubeless Ready, 51 mm rim depth, SRAM XD-R driver or Shimano 11/12-speed freehub, 142x12 mm thru axle
Front skewer: Bontrager Switch chamfered thru axle
Rear skewer: Bontrager Switch chamfered thru axle, removable lever
Tire: Bontrager Aeolus RSL RD, Tubeless-Ready, cotton construction, aramid bead, 170 tpi, 700x28 mm / Pirelli P Zero Race, 120 tpi, tubeless-compatible, 700x28 mm
Tire part: Bontrager TLR sealant, 180 ml / 6 oz
Tube: Pirelli P Zero SmarTube, TPU
Max tyre size: 32 mm (as measured, see manual for details)
Components
Saddle:
Size: XS, S – Aeolus RSL, carbon rails, 155 mm width
Size: M, ML, L, XL – Aeolus RSL, carbon rails, 145 mm width
Seatpost: Madone aero carbon seat post, 0 mm offset, short length
Handlebar/stem (integrated):
Size: XS – Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 35 cm control width, 38 cm drop width, 80 mm stem length
Size: S – Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 37 cm control width, 40 cm drop width, 90 mm stem length
Size: M – Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 39 cm control width, 42 cm drop width, 90 mm stem length
Size: ML, L – Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 39 cm control width, 42 cm drop width, 100 mm stem length
Size: XL – Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 41 cm control width, 44 cm drop width, 110 mm stem length
Handlebar tape: Trek EcoTack
Brakes
Brake rotor: SRAM Paceline X, rounded, CentreLock, 160 mm
Max brake rotor sizes: 180 mm front, 160 mm rear
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
