*Please note – spec applies to all sizes unless listed separately
Frameset
Frame: Alpha Platinum Aluminium, Removable Integrated Battery (RIB 2.0), tapered headtube, guided internal routing, Motor Armor, angle-adjust headset, Mino Link adjustable geometry, adjustable leverage rate, 34.9 mm seat tube, ABP, UDH, rack and mudguard mounts, Boost 148, 120 mm travel
Fork: RockShox Recon Silver, Solo Air spring, Motion Control damper, lockout, tapered steerer, 42mm offset, Boost110, Maxle Stealth, mudguard mounts, 130mm travel
Shock: RockShox Deluxe Select R, 210x50 mm
Max compatible fork travel: See service manual
Wheels
Hub (front): Shimano TC500 alloy, CentreLock, 110x15 mm thru axle
Hub (rear): Shimano TC500 alloy, CentreLock, 148x12 mm thru axle
Skewer rear: Bontrager Switch thru-axle, removable lever
Rim: Bontrager Line TLR 30, Tubeless-Ready, 28-hole (S, M, L, XL), 32-hole (S, M, L, XL), Presta valve
Spokes: 14 g stainless steel, black
Tyre: S – Bontrager Gunnison Pro XR, Tubeless-Ready, wire bead, 60 tpi, 27.5x2.40"
M, L, XL – Bontrager Gunnison Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 29x2.40"
Rim strip: Bontrager TLR
Max tyre size: Frame: 29x2.50" (S: 27.5x2.50"), Fork: see manufacturer
E-system
Battery: Bosch PowerTube 800 Wh, smart system
Charger: Bosch standard 2A, 230V, smart system
Computer: Bosch Purion 200
Motor: Bosch Performance Line CX, 20 mph / 32 km/h max assist (25 km/h in EU & APAC)
Drivetrain
Shifter: Shimano U6000, 10-speed
Rear derailleur: Shimano CUES U6000 GS
Crank: FSA Bosch CK-220, 36T ring, 165 mm length
Chainring: FSA, 36T, steel
Cassette: Shimano CUES LG300, LINKGLIDE, 11-48, 10-speed
Chain: Shimano LG500, 9/10/11-speed
Pedal: VP-536 nylon platform
Max. chainring size: 1x: 38T
Components
Saddle: Bontrager Commuter Comp
Seatpost:
S – Bontrager Line Dropper, 100 mm travel, MaxFlow, internal routing, 31.6 mm, 310 mm length
M, L, XL – Bontrager Line Dropper, 170 mm travel, MaxFlow, internal routing, 31.6 mm, 450 mm length
Handlebar: Bontrager Comp, alloy, 31.8 mm, 40 mm rise, 780 mm width
Grips: S, M, L, XL – Bontrager XR Trail Comp & Trek Line Comp, nylon lock-on
Stem: Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length
Headset: FSA IS-2, 1-1/8" top, 1.5" bottom
Brakes
Brake: Tektro Gemini SL 4 piston hydraulic brake
Brake rotor: Tektro, CentreLock, 203 mm
Rotor size: Max brake rotor sizes – Frame: 220 mm, min 180 mm, Fork: see fork manufacturer
Accessories
Light: S, M, L, XL – Supernova Mini 3 pure, LED, headlight & Supernova TL3 Mini, LED
Kickstand: Pletscher Comp Flex 18
Cargo rack: MIK-compatible alloy rear rack
Mudguard: S – Trek Powerfly 27.5" custom fender
M, L, XL – Trek Powerfly 29" custom fender
Weight
Weight limit: This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb)
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
