Please note – spec applies to all sizes unless listed separately.
Frameset
Fork: Sizes XS, S, M, L and XL: Carbon, hidden mudguard mounts, flat-mount disc, 100x5 mm thru-skew
Weight
Weight: Size M – 10.60 kg / 23.37 lbs
Weight limit: This bike has a maximum total weight limit, including the bicycle, rider and cargo, of 136 kg / 300 lbs.
Drivetrain and brakes
Shifter: SRAM Apex, 11-speed
Rear derailleur: SRAM Apex 1, long cage, 42T max cog
Crank: Prowheel alloy, 42T narrow-wide ring, 175 mm length
Cassette: microSHIFT XLE, 11-42, 11-speed
Chain: KMC X11
Pedals: Bontrager City pedals
Maximum chainring size: 1x: 44T, 2x: 46/32
Maximum brake rotor size: 160 mm front and rear
Wheels and tyres
Front hub: Formula CL-51 alloy, 100x5 mm
Rear hub: Formula CL-52 alloy, 135x5 mm
Rims: Sizes XS, S, M, L and XL: Bontrager Paradigm, Tubeless Ready, 32-hole, 21 mm width, Presta valve
Spokes: 14 g stainless steel, black
Tyres: Bontrager GR1 Expert, Hard-Case Lite, wire bead, 60 tpi, 700x40 mm
Maximum tyre size: 700x42 mm
Cockpit
Handlebar: Sizes XS and S: Bontrager alloy, 31.8 mm, 15 mm rise, 600 mm width / Sizes M, L and XL: Bontrager alloy, 31.8 mm, 15 mm rise, 660 mm width
Grips: Trek Ergonomic Pro, lock-on
Stem: Size XS: Bontrager Elite, 31.8 mm, Blendr compatible, 7-degree, 90 mm length / Sizes S and M: Bontrager Elite, 31.8 mm, Blendr compatible, 7-degree, 100 mm length / Sizes L and XL: Bontrager Elite, 31.8 mm, Blendr compatible, 7-degree, 110 mm length
Additional Features
Saddle: Bontrager Verse P3, chromoly rails
Seatpost: Bontrager Comp, 6061 alloy, 27.2 mm, 8 mm offset, 330 mm length
Care Instructions
We reserve the right to make changes to the product information at any time without notice, including equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted without notice.
Bike and frame weights are based on pre-production painted frames at the time of publication. Final production weights may vary.
