*Please note – spec applies to all sizes unless listed separately
Frameset
Frame: 400 series OCLV Carbon, internal routing, 3s chain keeper, DuoTrap S compatible, mudguard mounts, flat mount disc, 135x5mm ThruSkew
Fork: Carbon, hidden fender mounts, flat mount disc, 100x5mm thru-skew
Weight
Weight: M – 10.30 kg / 22.71 lbs
Weight limit: 136 kg (300 lb)
Drivetrain
Shifter: SRAM Apex, 11-speed
Rear derailleur: SRAM Apex 1, long cage, 42T max cog
Crank arm: Prowheel alloy, 42T narrow-wide ring, 175 mm length
Cassette: microSHIFT XLE, 11-42, 11-speed
Pedal: Bontrager City pedals
Max. chainring size: 1x: 44T
Wheels
Hub front: Formula CL-51 alloy, 100x5 mm QR
Skewer front: 135x5 mm bolt-on
Hub rear: Formula CL-52 alloy, 135x5 mm QR
Skewer rear: 169x5 mm bolt-on
Rim: Bontrager Paradigm, Tubeless Ready, 32-hole, 21 mm width, Presta valve
Tyre: Bontrager GR1 Expert, Hard-Case Lite, wire bead, 60 tpi, 700x40 mm
Max tyre size: 42 mm without mudguards, 40 mm with mudguards
Components
Saddle: Bontrager Montrose Comp, steel rails, 138 mm width
Seatpost: Bontrager Comp, 6061 alloy, 27.2 mm, 8 mm offset, 330 mm length
Handlebar:
Size: XS, S – Bontrager Satellite Plus IsoZone, alloy, 31.8 mm, 15 mm rise, 600 mm width
Size: M, L, XL – Bontrager Satellite Plus IsoZone, alloy, 31.8 mm, 15 mm rise, 660 mm width
Grips: Bontrager Satellite IsoZone Plus, lock-on, ergonomic
Stem:
Size: XS – Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 90 mm length
Size: S, M – Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 100 mm length
Size: L, XL – Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 110 mm length
Brakes
Brake: Shimano hydraulic disc, MT201 lever, UR300 caliper
Brake rotor: Shimano RT10, CenterLock, 160 mm
Rotor size: Max brake rotor sizes: 160 mm front and rear
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
