*Please note – spec applies to all sizes unless listed separately
Frameset
Frame: 400 series OCLV Carbon, internal routing, 3s chain keeper, DuoTrap S compatible, mudguard mounts, flat mount disc, 135x5mm ThruSkew
Fork: Carbon, hidden fender mounts, flat mount disc, 100x5mm thru-skew
Weight
Weight: M – 9.50 kg / 20.95 lbs
Weight limit: 136 kg (300 lb)
Drivetrain
Rear derailleur: SRAM Apex XPLR eTap AXS, 44T max cog
Crank arm:
Size: XS, S – SRAM Apex 1, 40T, DUB Wide, 170 mm length
Size: M, L, XL – SRAM Apex 1, 40T, DUB Wide, 175 mm length
Bottom bracket: SRAM DUB, 86.5 mm, PressFit
Cassette: SRAM XPLR PG-1231, 11-44, 12-speed
Chain: SRAM Apex, 12-speed
Pedal: VPE-993T
Max. chainring size: 1x: 44T
Wheels
Wheel front: Bontrager Aeolus Elite 35, OCLV Carbon, Tubeless Ready, 100x5mm QR
Wheel rear: Bontrager Aeolus Elite 35, OCLV Carbon, Tubeless Ready, Shimano 11-speed freehub, 135x5mm skewer
Hub front: Bontrager Affinity, Tubeless Ready, centerlock, 100x5mm axle
Skewer front: 135x5 mm bolt-on
Hub rear: Bontrager Affinity Comp, Shimano 11/12 speed freehub, 142x5mm
Skewer rear: 169x5 mm bolt-on
Tyre: Bontrager Girona Pro, Tubeless Ready, GR puncture protection, aramid bead, 60 tpi, 700x42 mm
Max tyre size: 42 mm without mudguards, 40 mm with mudguards
Components
Saddle: Bontrager Montrose Comp, steel rails, 138 mm width
Seatpost: Bontrager Comp, 6061 alloy, 27.2 mm, 8 mm offset, 330 mm length
Handlebar:
Size: XS, S, M – Bontrager Satellite Plus IsoZone, alloy, 31.8 mm, 15 mm rise, 600 mm width
Size: L, XL – Bontrager Satellite Plus IsoZone, alloy, 31.8 mm, 15 mm rise, 660 mm width
Grips: Bontrager Satellite IsoZone Plus, lock-on, ergonomic
Stem:
Size: XS – Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 90 mm length
Size: S, M – Bontrager Elite, 31.8 mm clamp, Blendr-compatible, 7-degree, 100 mm length
Size: L, XL – Bontrager Elite, 31.8 mm clamp, Blendr-compatible, 7-degree, 110 mm length
Brakes
Brake: Shimano hydraulic disc, MT201 lever, UR300 calliper
Brake rotor: Shimano RT10, CenterLock, 160 mm
Rotor size: Max brake rotor sizes: 160 mm front and rear
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
