*Please note – spec applies to all sizes unless listed separately
Frameset
Frame: Alpha Gold Aluminium, internal cable routing, rack & mudguard mounts, post mount disc, kickstand mount, 135x5mm QR
Fork: Dual Sport alloy, internal brake routing, mudguard mounts, rack mounts, ThruSkew 5mm QR
Weight
Weight: L – 14.40 kg / 31.75 lbs
Weight limit: 136 kg (300 lb)
Drivetrain
Shifter: Shimano U4000, 9-speed
Rear derailleur: Shimano CUES U4000
Crank arm: ProWheel Pro alloy, 40T narrow-wide steel ring, 170 mm length
Bottom bracket: Sealed cartridge, 68 mm
Cassette: Shimano LINKGLIDE LG300, 11-46, 9-speed
Chain: Shimano LG500
Pedal: Wellgo nylon body, alloy cage
Wheels
Hub front: Shimano 3.0 watt dynamo hub
Skewer front: 139x5 mm bolt-on
Hub rear: Shimano FH-QC300-HM, 32-hole, CentreLock, 8-/9-/10-/11-speed, 135x5 mm QR
Skewer rear: 152x5 mm QR
Rim: Bontrager Connection, double-wall, 32-hole, 20 mm width, Schrader valve
Tyre: Bontrager GR0 Comp, wire bead, reflective strip, 60 tpi, 650x50 mm
Components
Saddle: Bontrager Commuter Comp
Seatpost: Bontrager alloy, 27.2 mm, 12 mm offset, 330 mm length
Handlebar:
Size: S – Bontrager alloy, 31.8 mm, 15 mm rise, 600 mm width
Size: M – Bontrager alloy, 31.8 mm, 15 mm rise, 660 mm width
Size: L, XL – Bontrager alloy, 31.8 mm, 15 mm rise, 690 mm width
Grips: Trek Line Ergonomic Comp, lock-on
Stem:
Size: S – Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 70 mm length
Size: M – Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 80 mm length
Size: L – Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 90 mm length
Size: XL – Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 100 mm length
Brakes
Brake: Shimano hydraulic disc, MT201 lever, UR300 calliper
Brake rotor: Shimano RT10, CenterLock, 160 mm
Accessories
Light:
Size: S, M, L, XL – Herrmans H-Trace ECO dynamo LED, taillight
Size: S, M, L, XL – Herrmans Nordic MR5, 100 lumen, LED, with stand light function
Kickstand: Alloy, rear-mount
Cargo rack: MIK-compatible alloy rear rack
Mudguard:
Size: S, M, L, XL – SKS wide
Size: S, M, L, XL – Dual Sport plastic mudguard
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
