*Please note – spec applies to all sizes unless listed separately
Frameset
Frame: Alpha Gold Aluminium, internal cable routing, rack & mudguard mounts, post mount disc, kickstand mount, 135x5mm QR
Fork: FX steel, flat-mount disc, rack mounts, 410 mm axle-to-crown, ThruSkew 5 mm QR
Wheels
Hub front: Formula DC-20, alloy, 6-bolt, 5x100 mm QR
Skewer front: 139x5 mm bolt-on
Hub rear: Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR
Skewer rear: 152x5 mm QR
Tyre: Bontrager H2 Comp, wire bead, 30 tpi, 700x35 mm
Drivetrain
Shifter:
Size: XS, S, M, L, XL – Shimano EF500, 2-speed
Size: XS, S, M, L, XL – Shimano EF500, 8-speed
Front derailleur: Shimano Tourney TY606, 31.8/34.9 mm clamp, top swing, dual pull
Rear derailleur: Shimano Acera M3020-8, 40T max cog
Crank arm: Forged alloy, 46/30, 170 mm length
Bottom bracket: Sealed cartridge, 68 mm
Cassette: Shimano 8-speed, 12-32T
Chain: KMC Z8.3
Pedal: Wellgo nylon platform
Components
Saddle: Bontrager Sport
Seatpost:
Size: XS, S, M – Bontrager alloy, 27.2 mm, 12 mm offset, 330 mm length
Size: L, XL – Bontrager alloy, 27.2 mm, 12 mm offset, 400 mm length
Handlebar:
Size: XS, S, M, L – Bontrager Riser, steel, 25.4 mm, 30 mm rise, 600 mm width
Size: XL – Bontrager Riser, steel, 25.4 mm, 30 mm rise, 620 mm width
Grips: Trek Line Ergonomic Comp, lock-on
Stem:
Size: XS, S, M – Bontrager alloy, 25.4 mm clamp, 10-degree, 90 mm length
Size: L, XL – Bontrager alloy, 25.4 mm clamp, 10-degree, 110 mm length
Brake: Tektro MD-U310 mechanical disc
Brake rotor: Tektro wave, 6-bolt, 160 mm
Weight
Weight limit: This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb)
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
