*Please note – spec applies to all sizes unless listed separately
Frameset
Frame: 500 Series OCLV Carbon, IsoSpeed, internal storage, tapered head tube, internal cable routing, 3S chain keeper, mudguard mounts, flat mount disc, 142x12mm thru axle
Fork: Domane SL carbon, tapered carbon steerer, internal brake routing, mudguard mounts, flat-mount disc, 12x100 mm thru axle
Weight limit: 125 kg (275 lb)
E-system
Battery: Shimano BT-DN300
Charger: Charging cable included
Drivetrain
Shifter: Shimano 105 R7170, 12-speed
Front derailleur: Shimano 105 R7150 Di2, braze-on, down swing
Rear derailleur: Shimano 105 R7150 Di2, 36T max cog
*Crank:
Size:44, 47, 50 – Shimano 105 R7100, 50/34, 165mm length
Size:52, 54, 56 – Shimano 105 R7100, 50/34, 170mm length
Size:58, 60, 62 – Shimano 105 R7100, 50/34, 172.5mm length
Bottom bracket: Praxis, T47 threaded, internal bearing
Cassette: Shimano 105 7101, 11-34, 12-speed
Chain: Shimano SLX M7100, 12-speed
Max. chainring size: 1x: 48T, 2x: 52/36
Wheels
Wheel front: Bontrager Aeolus Elite 35, OCLV Carbon, Tubeless Ready, 35 mm rim depth, 100x12 mm thru axle
Wheel rear: Bontrager Aeolus Elite 35, OCLV Carbon, Tubeless Ready, 35 mm rim depth, Shimano 11-speed freehub, 142x12 mm thru axle
Hub front: Bontrager alloy, sealed bearing, CenterLock disc, 100x12 mm thru axle
Skewer front: Bontrager Switch thru-axle, removable lever
Hub rear: Bontrager Affinity Comp, Shimano 11/12 speed freehub, 142x12 mm thru axle
Skewer rear: Bontrager Switch thru-axle, removable lever
Rim: Bontrager Aeolus Elite 35, OCLV Carbon, Tubeless Ready, 35 mm rim depth
Rim strip: Bontrager TLR
Max tyre size: 38 mm without mudguards, 35 mm with mudguards
Components
Saddle: Verse Short Comp, steel rails, 145 mm width
*Seatpost:
Size:44-56 – KVF aero carbon seat post, 20 mm offset, 280 mm length
Size:58-62 – KVF aero carbon seat post, 20 mm offset, 320 mm length
*Handlebar:
Size:44,47 – Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 36 cm control width, 40 cm drop width
Size:50,52 – Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 38 cm control width, 42 cm drop width
Size:54,56,58 – Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 40 cm control width, 44 cm drop width
Size:60,62 – Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 42 cm control width, 46 cm drop width
Handlebar tape: Trek EcoTack
*Stem:
Size:44 – Trek RCS Pro, -7-degree, 60 mm length
Size:47 – Trek RCS Pro, -7-degree, 70 mm length
Size:50 – Trek RCS Pro, -7-degree, 80 mm length
Size:52,54 – Trek RCS Pro, -7-degree, 90 mm length
Size:56,58 – Trek RCS Pro, -7-degree, 100 mm length
Size:60,62 – Trek RCS Pro, -7-degree, 110 mm length
Brakes
*Brake rotor:
Size:44-62 – Shimano CL700, CentreLock, 160 mm
Size:44-62 – Shimano RT70, CentreLock, 160 mm
Rotor size: Max brake rotor sizes: 160 mm front and rear
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
