Please note – spec applies to all sizes unless listed separately.
Frameset
Frame: OCLV Mountain Carbon main frame, Removable Integrated Battery (RIB 2.0), tapered head tube, guided internal routing, Motor Armor, angle-adjust headset, Mino Link adjustable geometry, adjustable leverage rate, 34.9 mm seat tube, ABP, UDH, Boost 148, 12 mm thru axle, 160 mm travel
Fork: Fox Factory 38, Float EVOL air spring, GRIP X2 damper, 44 mm offset, Boost 110, 15 mm Kabolt X axle, 160 mm travel
Shock: Fox Factory Float X, 2-position damper, 205x65 mm
E-system
Motor: Bosch Performance Line CX, Europe and APAC: 25 km/h / US and ROW: 20 mph / 32 km/h
Battery: Bosch PowerTube 800 Wh, Smart System
Charger: Bosch standard 4A, 230V, Smart System
Controller: Bosch Kiox 400C, Mini Remote
Maximum assist speed: 15.5 mph
Drivetrain and brakes
Shifter: Shimano XT Di2 M8250, 12-speed
Rear derailleur: Shimano XT Di2 M8260, 12-speed
Crank arms: E*thirteen E*spec Plus, 160 mm length
Chainring: E*thirteen, 34T, steel
Cassette: Shimano XT M8200, 10-51, 12-speed
Chain: Shimano XT M8100, 12-speed
Pedals: VP-536 nylon platform
Maximum chainring size: 1x: 36T
Brakes: Shimano XT M8220, 4-piston hydraulic disc
Brake rotors: Sizes S, M, L and XL: Shimano RT-6B750, 6-bolt, 220 mm or Shimano RT-6B750, 6-bolt, 200 mm
Maximum brake rotor size: Frame: 220 mm / Fork: see fork manufacturer
Wheels and tyres
Front hub: Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Boost 110, 15 mm thru axle
Rear hub: Bontrager alloy, sealed bearing, 6-bolt, Rapid Drive 108, Shimano freehub, Boost 148, 12 mm thru axle
Rear skewer: Bontrager Switch thru axle, removable lever
Spokes: Sizes S, M, L and XL: 14 g stainless steel, black or 14 g stainless steel
Tyre sealant: Bontrager TLR sealant, 180 ml / 6 oz
Rim strip: Bontrager TLR
Maximum tyre size: Frame: 27.5x2.60" / Fork: see manufacturer
Cockpit
Handlebar: Bontrager Line Pro, OCLV Carbon, 35 mm, 27.5 mm rise, 820 mm width
Grips: Trek Line Elite, lock-on
Stem: Bontrager Elite, 35 mm, 0-degree, 45 mm length
Additional Features
Saddle: Verse Short Comp, steel rails, 145 mm width
Seatpost: Size S: Bontrager Line Elite Dropper, 150 mm travel, MaxFlow, internal routing, 34.9 mm, 440 mm length / Size M: Bontrager Line Dropper, 170 mm travel, MaxFlow, internal routing, 34.9 mm, 450 mm length / Sizes L and XL: Bontrager Line Dropper, 200 mm travel, MaxFlow, internal routing, 34.9 mm, 515 mm length
Weight
Weight: Size M – 23.98 kg / 52.87 lb, with TLR sealant and no tubes
Weight limit: This bike has a maximum total weight limit, including the bicycle, rider and cargo, of 136 kg / 300 lb.
We reserve the right to make changes to the product information at any time without notice, including equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted without notice.
Bike and frame weights are based on pre-production painted frames at the time of publication. Final production weights may vary.
