Frameset
Frame
500 Series OCLV Carbon, integrated frame bag mounts, integrated rack, T47, UDH, 142x12 mm chamfered thru axle, 55 mm travel
Fork
RockShox Rudy XL Ultimate, Charger Race Day 2 Solo Air spring, tapered steerer, 45 mm offset, 12x100 mm thru axle, 60 mm travel
Shock
RockShox SIDluxe Ultimate 3P, 170 mm x 27.5 mm
Weight
Weight
ML - 11.97 kg / 26.39 lbs (with TLR sealant, no tubes, excluding rear rack)
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg / 275 lb
Drivetrain
Rear derailleur
Shimano GRX RX822, 51T max cog
Crank
- Size S: Shimano GRX RX610, 38T, 160 mm length
- Size M, ML: Shimano GRX RX610, 38T, 170 mm length
- Size L, XL: Shimano GRX RX610, 38T, 172.5 mm length
Bottom bracket
Praxis, T47 threaded, internal bearing
Cassette
Shimano XT M8200, 10-51, 12-speed
Chain
Shimano XT M8100, 12-speed
Max. chainring size
1x: 38T
Wheels
Wheel front
Bontrager Paradigm Comp 25, Tubeless Ready, 25 mm rim width, 100x12 mm thru axle
Skewer rear
Bontrager Switch chamfered thru axle, removable lever
Rim
Bontrager Paradigm Comp 25, Tubeless-Ready, 25 mm rim width
Tyre
Bontrager Betasso RSL GX, Tubeless ready, aramid bead, 60 tpi, 700x55 mm
Tyre part
Bontrager TLR sealant, 180 ml / 6 oz
Rim strip
Bontrager TLR
Max tyre size
56 mm / 2.20" (as measured, see manual for details)
Components
Saddle
Verse Short Comp, steel rails, 145 mm width
Seatpost
TranzX JD-YSI36, 100 mm travel, internal routing, 31.6 mm, 328 mm length
Handlebar
- Size S: Bontrager GR Checkout, 42 cm
- Size M: Bontrager GR Checkout, 44 cm
- Size ML, L: Bontrager GR Checkout, 46 cm
- Size XL: Bontrager GR Checkout, 48 cm
Handlebar tape
Bontrager Supertack Perf tape
Stem
- Size S, M: Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 60 mm length
- Size ML, L: Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 70 mm length
- Size XL: Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length
Rotor size
Max brake rotor sizes: 180 mm front and rear
Accessories
Cargo rack
Checkout rear rack
Notes
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
