Frameset
Frame: High-performance hydroformed alloy, Removable Integrated Battery, internal cable routing, Motor Armour, post-mount disc
Fork: SR Suntour NVX30, coil spring, preload adjuster, 100 mm QR, 60 mm travel
Max compatible fork travel: 63 mm
Wheels
Front hub: Alloy, CenterLock disc, 100 mm thru axle
Rear hub: Shimano Nexus C7000, 5-speed
Rim: Bontrager Connection, double-wall, 32-hole, 20 mm width, Presta valve
Spokes: 14 g stainless steel, black
Tyre: Bontrager E6 Hard-Case Lite, reflective strip, 27.5x2.40"
Max tyre size: 27.5x2.40"
E-system
Charger: Bosch standard 4A, 230V, smart system
Controller: Bosch Intuvia 100, smart system
Computer: Bosch LED remote, smart system
Motor: Bosch Performance Line, 250 W, 75 Nm, 20 mph (25 km/h in Europe)
Drivetrain
Shifter: Shimano Nexus C7000, 5-speed
Crank: ProWheel alloy, 175 mm length
Chainring: Gates CDX, 46T
Cassette: Gates CDX, 32T
Pedal: Bontrager City pedals
Max. chainring size: 50T (Gates belt sprocket)
Components
Saddle: Bontrager Boulevard
Seatpost: Alloy, suspension, 31.6 mm, 300 mm length
Handlebar: Alloy, 31.8 mm clamp, 25 mm rise, 630 mm width
Grips: Bontrager Satellite Elite, alloy lock-on
Stem: Bontrager alloy, 31.8 mm clamp, adjustable rise, Blendr-compatible, 105 mm length
Brakes
Brake: Tektro HD-M275 hydraulic disc
Brake rotor: Shimano EM300, CenterLock, 160 mm / Shimano RT10, CenterLock, 160 mm
Rotor size: Max brake rotor sizes: 180 mm front and rear
Accessories
Light: Spanninga SOLO for e-bike / Herrmans MR4, 120-lumen LED
Kickstand: Pletscher Comp Flex 18
Cargo rack: Alloy rear rack, 25 kg max weight
Mudguard: SKS plastic, front & rear
Weight
Weight: L - 26.20 kg / 57.77 lbs (excluding battery)
Weight limit: 136 kg / 300 lb (combined weight of bicycle, rider and cargo)
