Please note – spec applies to all sizes unless listed separately.
Frameset
Frame: Alpha Smooth Aluminium, internal cable routing
Fork: Rigid aluminium
E-system
Motor: Bosch Hub Drive, 45 Nm, 250 W, max. 25 km/h
Battery: Bosch PowerTube 360 Wh, Smart System
Charger: Bosch standard 2A, 230V, Smart System
Computer: Bosch Purion 200
Maximum assist speed: 15.5 mph
Drivetrain and brakes
Shifter: Shimano M315, 8-speed
Rear derailleur: Shimano ESSA U2000
Crank: 42T with tone wheel for Bosch sensor
Bottom bracket: Cartridge
Cassette: Shimano HG300, 11-45, 8-speed
Chain: KMC Z8
Pedals: VP-536 nylon platform
Brakes: Shimano hydraulic disc, MT201 lever, UR300 calliper
Brake rotors: Sizes M, L and XL: Shimano RT30, CentreLock, 180 mm or Shimano RT26, 6-bolt, 180 mm
Wheels and tyres
Front hub: Shimano Tourney HB-QC300, CenterLock
Front skewer: 139x5 mm bolt-on
Rear skewer: Bontrager Switch thru axle, removable lever
Rim: Bontrager Kovee, double-wall, Tubeless Ready, 32-hole, 23 mm width, Presta valve
Tyres: Bontrager Girona Comp, sub-tread puncture protection, black sidewall, reflective stripe, 700x50C, made with recycled content
Cockpit
Handlebar: Alloy low-riser, 31.8 mm, 25 mm rise, 11-degree backsweep, 690 mm width
Grips: Sizes M, L and XL: Trek Ergonomic Comp, lock-on or Trek Ergonomic PRO, lock-on
Stem: Size M: Bontrager alloy, 31.8 mm clamp, adjustable rise, Blendr compatible, 70 mm length / Sizes L and XL: Bontrager alloy, 31.8 mm clamp, adjustable rise, Blendr compatible, 110 mm length
Additional Features
Saddle: Selle Royal Vivo Moderate Ergo
Seatpost: Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length
Lights: Sizes M, L and XL: Spanninga SOLO e-bike taillight and Herrmans H-Black MR4-E, 120 lumen, 40 lux, LED headlight
Kickstand: Pletscher Comp Flex 40
Cargo rack: Alloy rear rack, MIK compatible
Mudguards: Sizes M, L and XL: SKS plastic front and rear mudguards
Weight
Weight: Size L – 19.40 kg / 42.77 lbs, excluding battery and pedals
Weight limit: This bike has a maximum total weight limit, including the bicycle, rider and cargo, of 136 kg / 300 lb.
We reserve the right to make changes to the product information at any time without notice, including equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted without notice.
Bike and frame weights are based on pre-production painted frames at the time of publication. Final production weights may vary.
