*Please note – spec applies to all sizes unless listed separately
Frameset
Frame:
Size: XS – Alpha Silver Aluminium, curved top tube, internal derailleur and dropper post routing, rack and kickstand mount, 135x5 mm ThruSkew
Size: S, M, ML, L, XL, XXL – Alpha Silver Aluminium, internal derailleur and dropper post routing, rack and kickstand mount, 135x5 mm ThruSkew
Fork:
Size: XS – SR Suntour XCE 28, coil spring, preload, 42 mm offset for 27.5" wheel, 100 mm QR, 80 mm travel
Size: S – SR Suntour XCE 28, coil spring, preload, 42 mm offset for 27.5" wheel, 100 mm QR, 100 mm travel
Size: M, ML, L, XL, XXL – SR Suntour XCE 28, coil spring, preload, 46 mm offset for 29" wheel, 100 mm QR, 100 mm travel
Wheels
Hub (front): Formula DC-20, alloy, 6-bolt, 5x100 mm QR
Hub (rear): Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR
Rear skewer: 173x5 mm QR
Rim: Bontrager Connection, double-wall, 32-hole, 20 mm width, Schrader valve
Tyres:
Size: XS, S – Bontrager Montrose Comp, wire bead, 30 tpi, 27.5x2.40"
Size: M, ML, L, XL, XXL – Bontrager Montrose Comp, wire bead, 30 tpi, 29x2.40"
Drivetrain
Shifter: Shimano M315, 8-speed
Rear derailleur: Shimano ESSA U2000
Crank:
Size: XS – ProWheel alloy, 32T narrow-wide steel ring, 160 mm length
Size: S, M, ML – ProWheel alloy, 32T narrow-wide steel ring, 170 mm length
Size: L, XL, XXL – ProWheel alloy, 32T narrow-wide steel ring, 175 mm length
Cassette: Shimano HG300, 11-45, 8-speed
Chain: KMC Z8.3, 8-speed
Pedal: Nylon platform
Components
Saddle: Bontrager Verse Short, stainless steel rails
Seatpost:
Size: XS, S, M – Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length
Size: ML, L, XL, XXL – Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length
Handlebar:
Size: XS – Bontrager alloy, 31.8 mm, 5 mm rise, 690 mm width
Size: S – Bontrager alloy, 31.8 mm, 15 mm rise, 720 mm width
Size: M, ML, L, XL, XXL – Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width
Grips: Trek Line Comp, nylon lock-on
Stem:
Size: XS, S – Bontrager Comp, 31.8 mm, 7-degree, 35 mm length
Size: M, ML, L – Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length
Size: XL – Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 60 mm length
Size: XXL – Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 70 mm length
Headset: Semi-integrated, 1-1/8"
Brakes
Brake:
Size: XS, S – Tektro HD-M276 hydraulic disc
Size: M, ML, L, XL, XXL – Tektro HD-M275 hydraulic disc
Brake rotor:
Size: XS, S, M, ML, L, XL, XXL – Tektro, 6-bolt, 160 mm
Size: M, ML, L, XL, XXL – Tektro, 6-bolt, 180 mm
Weight
Weight: M – 14.90 kg / 32.85 lbs
Weight limit: 136 kg (300 lb)
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
