*Please note – spec applies to all sizes unless listed separately
Frameset
Frame: 500 Series OCLV Carbon, IsoSpeed, internal storage, tapered head tube, internal cable routing, 3S chain keeper, mudguard mounts, flat mount disc, 142x12mm thru axle
Fork: Domane SL carbon, tapered carbon steerer, internal brake routing, mudguard mounts, flat-mount disc, 12x100 mm thru axle
Weight limit: 125 kg (275 lb)
Drivetrain
Shifter: Shimano 105 R7120, 12-speed
Front derailleur: Shimano 105 R7100, braze-on, down swing
Rear derailleur: Shimano 105 R7100, 36T max cog
*Crank:
Size:44, 47, 50 – Shimano 105 R7100, 50/34, 165mm length
Size:52, 54, 56 – Shimano 105 R7100, 50/34, 170mm length
Size:58, 60, 62 – Shimano 105 R7100, 50/34, 172.5mm length
Bottom bracket: Praxis, T47 threaded, internal bearing
Cassette: Shimano 105 7101, 11-34, 12-speed
Chain: Shimano SLX M7100, 12-speed
Max. chainring size: 1x: 48T, 2x: 52/36
Wheels
Hub front: Bontrager alloy, sealed bearing, CenterLock disc, 100x12 mm thru axle
Skewer front: Bontrager Switch thru-axle, removable lever
Hub rear: Bontrager alloy, sealed bearing, CenterLock disc, Shimano 11-speed freehub, 142x12 mm thru axle
Skewer rear: Bontrager Switch thru-axle, removable lever
Rim: Bontrager Paradigm 23, Tubeless Ready, 24-hole, 23 mm width, Presta valve
Spokes: 14 g stainless steel, black
Tyre: Bontrager TLR sealant, 180 ml/6 oz
Max tyre size: 38 mm without mudguards, 35 mm with mudguards
Components
Saddle: Verse Short Comp, steel rails, 145 mm width
*Seatpost:
Size:44-56 – KVF aero carbon seat post, 20 mm offset, 280 mm length
Size:58-62 – KVF aero carbon seat post, 20 mm offset, 320 mm length
*Handlebar:
Size:44,47 – Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 36 cm control width, 40 cm drop width
Size:50,52 – Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 38 cm control width, 42 cm drop width
Size:54,56,58 – Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 40 cm control width, 44 cm drop width
Size:60,62 – Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 42 cm control width, 46 cm drop width
Handlebar tape: Trek EcoTack
*Stem:
Size:44 – Trek RCS Pro, -7-degree, 60 mm length
Size:47 – Trek RCS Pro, -7-degree, 70 mm length
Size:50 – Trek RCS Pro, -7-degree, 80 mm length
Size:52,54 – Trek RCS Pro, -7-degree, 90 mm length
Size:56,58 – Trek RCS Pro, -7-degree, 100 mm length
Size:60,62 – Trek RCS Pro, -7-degree, 110 mm length
Brakes
*Brake rotor:
Size:44-62 – Shimano CL700, CentreLock, 160
