Frameset
Frame: 500 Series OCLV Carbon, Full System Foil tube shaping, IsoFlow seat tube, RCS Headset System, electronic or mechanical routing, removable aero chain keeper, T47 BB, flat mount disc, UDH, 142x12 mm thru axle
Fork: Madone Gen 8 full carbon, tapered carbon steerer, internal brake routing, flat-mount disc, 12x100 mm chamfered thru-axle
Weight
Weight: Size ML - 7.87 kg / 17.36 lbs (with TLR sealant, no tubes)
Weight limit: This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg / 275 lb.
E-system
Battery: Shimano BT-DN300
Drivetrain
Shifter: Shimano Ultegra R8170 Di2, 12-speed
Front derailleur: Shimano Ultegra R8150 Di2, braze-on, down swing
Rear derailleur: Shimano Ultegra R8150 Di2, 34T max cog
Crank: Size XS, S: Shimano Ultegra R8100, 50/34, 160mm length / Size M, ML: Shimano Ultegra R8100, 50/34, 165mm length / Size L, XL: Shimano Ultegra R8100, 50/34, 170mm length
Bottom bracket: Praxis, T47 threaded, internal bearing
Cassette: Shimano Ultegra R8101, 11-34, 12-speed
Chain: Shimano XT M8100, 12-speed
Max. chainring size: 1x: 54T, 2x: 56/43
Wheels
Front wheel: Bontrager Aeolus Pro 51, OCLV Carbon, Tubeless Ready, 100x12 mm thru axle
Rear wheel: Bontrager Aeolus Pro 51, OCLV Carbon, Tubeless Ready, Shimano 11/12-speed freehub, 142x12 mm thru axle
Front skewer: Bontrager Switch chamfered thru axle
Rear skewer: Bontrager Switch chamfered thru axle, removable lever
Tyre: Bontrager Aeolus Pro, Tubeless Ready, aramid bead, 120 tpi, 700x28 mm
Tyre part: Bontrager TLR sealant, 180 ml / 6 oz
Max tyre size: 32mm (as measured, see manual for details)
Components
Saddle: Bontrager Aeolus Elite, austenite rails, 145 mm width
Seatpost: Madone aero carbon seat post, 0 mm offset, short length
Handlebar: Size XS: Bontrager Aero Pro, OCLV Carbon, 31.8 mm, Di2 routing, 80 mm reach, 124 mm drop, 35 cm control width, 38 cm width / Size S: Bontrager Aero Pro, OCLV Carbon, 31.8 mm, Di2 routing, 80 mm reach, 124 mm drop, 37 cm control width, 40 cm width / Size M, ML, L: Bontrager Aero Pro, OCLV Carbon, 31.8 mm, Di2 routing, 80 mm reach, 124 mm drop, 39 cm control width, 42 cm width / Size XL: Bontrager Aero Pro, OCLV Carbon, 31.8 mm, Di2 routing, 80 mm reach, 124 mm drop, 41 cm control width, 44 cm width
Handlebar tape: Trek EcoTack
Stem: Size XS: Trek RCS Pro, -7-degree, 80 mm length / Size S, M: Trek RCS, -7 degree, 90 mm length / Size ML, L: Trek RCS, -7 degree, 100 mm length / Size XL: Trek RCS, -7 degree, 110 mm length
Brake: Shimano Ultegra hydraulic disc, flat mount
Brake rotor: Shimano CL800, CentreLock, 160 mm
Rotor size: Max brake rotor sizes: 180 mm front, 160 mm rear
Additional note
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
