Frameset
Frame: High-performance hydroformed alloy, internal cable routing, external battery mount, post-mount disc, 135x5 mm QR
Fork: SR Suntour NVX30, coil spring, preload adjuster, 100 mm QR, 60 mm travel
Wheels
Front hub: Shimano Tourney HB-QC300, centerlock
Rear hub: Shimano FH-QC300-HM, 32-hole, CentreLock, 8-/9-/10-/11-speed, 135x5 mm QR
Rim: Bontrager Connection, double-wall, 32-hole, 20 mm width, Presta valve
Tyre: Bontrager E6 Hard-Case Lite, reflective strip, 27.5x2.40"
E-bike System
Charger: Bosch standard 2A, 230V, smart system
Computer: Bosch Purion 200
Motor: Bosch Performance Line CX, 20 mph (25 km/h in Europe)
Drivetrain
Shifter: Shimano U4000, 9-speed
Rear derailleur: Shimano CUES U4000
Crank: Size S & M: ProWheel alloy, 170 mm length
Size L & XL: ProWheel alloy, 175 mm length
Chainring: ProWheel 40T narrow/wide steel, with alloy guard
Cassette: Shimano LINKGLIDE LG300, 11-46, 9-speed
Chain: Shimano LG500, 9/10/11-speed
Pedal: Slip-proof pedals with reflectors
Components
Saddle: Selle Royal Vivo Moderate Ergo
Seatpost: Size S & M: Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length
Size L & XL: Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length
Handlebar: Alloy lowriser, 31.8 mm, 25 mm rise, 11-degree backsweep, 690 mm width
Grips: Herrmans Clik, ergonomic, lock-on
Stem: Size S: Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 70 mm length
Size M: Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 80 mm length
Size L & XL: Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 90 mm length
Brakes
Brake: Shimano MT200 hydraulic disc
Brake rotor: Size S, M, L, XL: Shimano RT30, CentreLock, 180 mm
Size S, M, L, XL: Shimano EM300, CentreLock, 180 mm
Accessories
Light: Size S, M, L, XL: Spanninga SOLO for e-bike
Size S, M, L, XL: Herrmans H-Black MR5-E, 140 Lumen, 40 Lux, LED, headlight
Kickstand: Pletscher Comp Flex 18
Cargo rack: MIK-compatible alloy rear rack, maximum load 25 kg
Mudguard: Size S, M, L, XL: SKS plastic, front & rear
Weight
Weight: M - 24.30 kg / 53.58 lbs (with 545Wh battery)
Weight limit: 136 kg / 300 lb (combined weight of bicycle, rider and cargo)
