Frame, Forks, Saddle and Cockpit
Frame: Carbon fiber, gravel category, battery integrated, inner cable routing, 12x142mm, 8 mounting points, rack compatible
Fork: Carbon gravel fork, 6 mounting points, 12x100mm, offset 50mm
Headset: Token TK155SP, Dia 28.6, Alloy dia top & bottom 52mm
Saddle: Fizik Terra Aidon X5
Seatpost: Velduro carbon, Dia 27.2mm, 380mm, BLK
Handlebar: Velduro alloy MTB straight, Dia 31.8mm, width 680mm, BLK
Stem: Velduro Alloy road stem, BLK, S&M: 75mm, L&XL: 95mm Length
Grips: Velduro MTB comfort, BLK
Drive Train & Brakes
Brakes: Sram S300 hydraulic, 2-piston
Discs: Sram Centerline, Front 160mm, Rear 160mm
Rear derailleur: Shimano Cues RD-U6000, 11-Speed
Cassette: Shimano Cues LG400-11S, 11-45T
Cranks: Avinox SL, 165mm
Spider: Avinox 104BCD
Chainwheel: Velduro customised alloy 44T, 3mm inward
Chain: Shimano LG500 Linkglide, BLK
Wheels & Tires
Front hub: Velduro, 2-bearings, BLK, 6-bolts, 13G*24H, 12x100mm
Rear hub: Velduro, 4-bearings, BLK, 6-bolts, 13G*24H, 12x142mm, HG freehub
Rims: 700C, Velduro alloy, BLK, 13G*24H, 25mm inner width, 25mm depth, with hook
Tires: Continental Terra Trail 700x45C, BLK, with tube
*Your Phantom is tubeless-ready, but comes with a tube.
Avinox Drive System
Motor: Avinox M1, 36V, 105Nm, 850W, boost to 120Nm, 1000W
Battery: Avinox 600Wh integrated
Display: Avniox DP100 integrated 2-inch display
Button: Avinox BC100 Wireless control, left & right
Charger: Avinox 4A charger
Cables: Avinox customised waterproof and foolproof wiring
