MOTOR | Bosch Performance Line CX (Gen 4). 85 Nm max Torque, 250 W nominal power, 2.79 kg 4 Power settings including progressive eMTB mode which automatically adjusts the support |
BATTERY | Bosch 625 Wh internal PowerTube. Reaches full charge in 5 hours with supplied 4A Compact Charger, 80% charge from 0 in 2.5 hours |
DISPLAY | Bosch Purion |
COLOUR | Matt Burnt Orange with Black & Earth |
CASSETTE | SRAM PG-1210 Eagle, 11-50, 12 Speed |
FRAME | 6061 Alloy, Hydro Formed T6 Aluminium, Multi Butted, Custom Drawn, Tapered Headtube, Internal Cable Routing for Dropper Post and 12mm X 148mm Boost Dropouts |
CHAIN | SRAM GX Eagle, 12 Speed |
FORK | RockShox ZEB 27.5", 160mm Travel, 44mm Offset, DebonAir, Charger R Damper, Fast Black Coating, Tapered Steerer, 110mm x 15mm Boost, Maxle Ultimate |
CRANKSET | SRAM EX1, 165mm, ISIS with X-SYNC 2, Direct Mount 34T for Bosch Gen 4, Black |
REAR SHOCK | RockShox Deluxe Select + RT, DebonAir, Fast Black Coating, Adjustable Rebound, 2 position compression adjustment |
BOTTOM BRACKET | N/A |
HEADSET | FSA No. 57E Orbit ZS, 1 1/2" Lower and 1 1/8" Upper Sealed Cartridge Bearings |
SEATPOST | Whyte drop.it Adjust, 30.9mm, XS/S 120-150mm Travel, M/L 140-170mm Travel, XL 170-200mm Travel, Paddle Remote Lever |
REAR HUB | Alloy, e-bike specific, Double Sealed Cartridge Bearings, 12mm x 148mm Boost Through Axle, 32 Hole |
SADDLE | Whyte Custom, Triple Panel Design |
FRONT HUB | Alloy, Double Sealed Cartridge Bearings, 15mm x 110mm Boost Through Axle, 31mm Torque Caps, 32 Hole |
HANDLEBAR | Whyte Custom 6061 Alloy, 30mm Rise, 35mm Bar Bore, 780mm Wide |
SPOKES | DT Swiss Champion 2.0mm, Black Stainless, Brass Nipples |
STEM | Whyte Enduro Stem, 35mm Bar Bore, 35mm Extension |
RIMS | WTB HTZ i30 TCS 2.0 System, Asymmetric, Sleeved Joint, Super Tough Construction, Tubeless Ready, 32 Hole |
GRIPS | Whyte Lock-on V Grip |
TYRE | WTB Verdict TCS System 27.5" X 2.5" Light/High Grip, Tri-Tec triple compound High Grip, Lightweight Casing with Slash Guard, Front, WTB Verdict TCS System 27.5" X 2.5" Tough/High Grip, Tri-Tec triple compound, Fast Rolling, Enduro Casing, Rear |
BRAKES FRONT | SRAM Guide RE, 4 Pot with Sintered Metal Pads, 220mm Rotor |
SHIFT LEVERS | SRAM GX-E, Single Click, MMX, 12 Speed |
BRAKES REAR | SRAM Guide RE, 4 Pot with Sintered Metal Pads, 200mm Rotor |
FRONT MECH | N/A |
BRAKE LEVERS | SRAM Guide RE, MMX |
REAR MECH | SRAM GX Eagle, 12 Speed |
WEIGHT | TBC |
