*Please note – spec applies to all sizes unless listed separately
Frameset
Frame: 500 Series OCLV Carbon, IsoSpeed, internal storage, tapered head tube, internal cable routing, 3S chain keeper, mudguard mounts, flat mount disc, 142x12mm thru axle
Fork: Domane SL carbon, tapered carbon steerer, internal brake routing, mudguard mounts, flat-mount disc, 12x100 mm thru axle
Weight limit: 125 kg (275 lb)
E-system
Battery: Shimano BT-DN300
Charger: Charging cable included
Drivetrain
Shifter: Shimano Ultegra R8170 Di2, 12-speed
Front derailleur: Shimano Ultegra R8150 Di2, braze-on, down swing
Rear derailleur: Shimano Ultegra R8150 Di2, 34T max cog
*Crank:
Size:44, 47, 50 – Shimano Ultegra R8100, 50/34, 165 mm length
Size:52, 54, 56 – Shimano Ultegra R8100, 50/34, 170 mm length
Size:58, 60, 62 – Shimano Ultegra R8100, 50/34, 172.5 mm length
Bottom bracket: Praxis, T47 threaded, internal bearing
Cassette: Shimano Ultegra R8101, 11-34, 12-speed
Chain: Shimano XT M8100, 12-speed
Max. chainring size: 1x: 48T, 2x: 52/36
Wheels
Wheel front: Bontrager Aeolus Pro 51, OCLV Carbon, Tubeless Ready, 100x12mm thru axle
Wheel rear: Bontrager Aeolus Pro 51, OCLV Carbon, Tubeless Ready, Shimano 11/12-speed freehub, 142x12 mm thru axle
Skewer front: Bontrager Switch thru-axle, removable lever
Skewer rear: Bontrager Switch thru-axle, removable lever
Rim: Bontrager Aeolus Pro 51, OCLV Carbon, Tubeless Ready
Tyre: Bontrager Kwaremont Pro GR, tubeless ready, folding bead, dual compound, 120 tpi, 700x32 mm
Tyre part: Bontrager TLR sealant, 180 ml/6 oz
Max tyre size: 38 mm without mudguards, 35 mm with mudguards
Components
Saddle: Verse Short Comp, steel rails, 145 mm width
*Seatpost:
Size:44-56 – KVF aero carbon seat post, 20 mm offset, 280 mm length
Size:58-62 – KVF aero carbon seat post, 20 mm offset, 320 mm length
*Handlebar:
Size:44,47 – Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 36 cm control width, 40 cm drop width
Size:50,52 – Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 38 cm control width, 42 cm drop width
Size:54,56,58 – Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 40 cm control width, 44 cm drop width
Size:60,62 – Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 42 cm control width, 46 cm drop width
Handlebar tape: Trek EcoTack
*Stem:
Size:44 – Trek RCS Pro, -7-degree, 60 mm length
Size:47 – Trek RCS Pro, -7-degree, 70 mm length
Size:50 – Trek RCS Pro, -7-degree, 80 mm length
Size:52,54 – Trek RCS Pro, -7-degree, 90 mm length
Size:56,58 – Trek RCS Pro, -7-degree, 100 mm length
Size:60,62 – Trek RCS Pro, -7-degree, 110 mm length
Brakes
Brake rotor:
Size:44-62 – Shimano CL800, CentreLock, 160 mm
Rotor size: Max brake rotor sizes: 160 mm front and rear
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
