Frameset
Frame: Orbea Rise SL OMR 2025, carbon frame, 140mm rear travel, 29" wheels, Concentric Boost 12x148
Shock: Fox Float Performance, 2-Position Evol LV, custom tune, 210x50mm
Fork: Fox 36 Float SL Performance, 140mm travel, Grip damper, 3-Position, 15x110
Steerer Tube: Alloy 1-1/2", Black Oxidated Bearing
E-Bike System
Battery: Orbea Internal 420Wh
Range Extender: N/A
Motor: Shimano EP600 RS Gen2 MC
Display: N/A
Remote: EN600-L
Charger: Orbea 2nd Generation eBike Smart Charger, 42V / 2–4A
Drivetrain
Chainring: e*thirteen Helix Core e*spec Direct Mount, 32T, 55mm Chainline
Crankset: Shimano Steps EM600
Shifters: Shimano SLX M7100 I-Spec EV
Cassette: Shimano CS-M7100, 10–51T, 12-Speed
Rear Derailleur: Shimano SLX M7100 SGS Shadow Plus
Chain: Shimano M6100
Chainguide: Orbea eBike chainguide
Cockpit & Brakes
Handlebar: OC Mountain Control MC31, Rise 20, Width 800mm
Stem: OC Mountain Control MC20, 0º
Computer Mount: OC Computer Mount CM-05, Garmin / Sigma
Brakes: Shimano M6100 Hydraulic Disc
Rotors: Shimano RT64, 180mm front / 180mm rear
Brakes Configuration: N/A
Wheels & Tyres
Wheels: Race Face AR 30c, Tubeless Ready
Front Tyre: Schwalbe Wicked Will Evo TLE, 29x2.40, Super Race, Soft Compound, Addix, Brown
Rear Tyre: Schwalbe Wicked Will Evo TLE, 29x2.40, Super Race, SpeedGrip, Addix, Brown
Components
Seatpost: OC Mountain Control MC22, 31.6mm, Dropper
Seatpost Lever: Shimano SL-MT500 I-Spec EV
Saddle: Fizik Terra Ridon X5, 145mm
Grips: OC Lock On
Accessories
Lights: N/A
Tools: N/A
