Frameset
Frame: High-performance hydroformed alloy, internal cable routing, external battery mount, post-mount disc, 135x5 mm QR
Fork: SR Suntour Mobie 34, air spring, rebound and compression adjust, tapered alloy steerer, 100x15mm thru axle, 60mm travel
Wheels
Front hub: Bontrager sealed bearing, 32-hole, 15 mm alloy thru-axle
Rear hub: Formula CL-52 alloy, 135x5 mm QR
Skewer rear: 148x5 mm bolt-on
Rim: Bontrager Kovee, double-wall, Tubeless Ready, 28-hole, 23 mm width, Presta valve
Tyre: Schwalbe G-One, Performance, RaceGuard, reflective strip, 57-584
E-system
Charger: Bosch standard 4A, 230V, smart system
Computer: Size S, M, L: Bosch Kiox 300, smart system / Bosch LED remote, smart system
Motor: Bosch Performance Line CX, 20 mph (25 km/h in Europe)
Drivetrain
Shifter: Shimano CUES U6000 w/ optical gear display, 10-speed
Rear derailleur: Shimano CUES U6000 GS
Crank: Size S, M: ProWheel alloy, 170 mm length
Size L: ProWheel alloy, 175 mm length
Chainring: ProWheel 40T narrow/wide steel, w/alloy guard
Cassette: Shimano CUES LG300, LINKGLIDE, 11-48, 10-speed
Chain: Shimano LG500, 9/10/11-speed
Pedal: Slip-proof pedals with reflectors
Components
Saddle: Bontrager Commuter Comp
Seatpost: Size S, M: Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length
Size L: Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length
Handlebar: Alloy lowriser, 31.8 mm, 25 mm rise, 11-degree backsweep, 690 mm width
Grips: Bontrager XR Endurance Elite
Stem: Size S, M: Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 80 mm length
Size L: Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 90 mm length
Brakes
Brake: Size S, M, L: Shimano MT401 / MT420 hydraulic disc, 180 mm rotor
Size S, M, L: Shimano MT401 / MT420 hydraulic disc
Brake rotor: Size S, M, L: Shimano RT30, CentreLock, 203 mm
Size S, M, L: Shimano EM300, CentreLock, 180 mm
Accessories
Light: Size S, M, L: Spanninga SOLO for e-bike / Herrmans H-Black MR9-E, 60 lux, LED, headlight
Kickstand: Pletscher Comp Flex 18
Cargo rack: MIK-compatible alloy rear rack, max load 25 kg
Mudguard: Size S, M, L: SKS plastic, front & rear
Weight
Weight: M - 23.10 kg / 50.93 lbs (with 545Wh battery)
Weight limit: 136 kg / 300 lb (combined weight of bicycle, rider and cargo)
