*Please note – spec applies to all sizes unless listed separately
Frameset
Frame: Premium Alpha Platinum Aluminum frame, top-load PowerPack, integrated cockpit routing, 135x5mm QR
Fork: SR Suntour SF25-NVX32, coil spring, preload adjuster, 5 mm ThruSkew, 63 mm travel
Wheels
Front Hub: Shimano Tourney HB-QC300, centerlock
Front Skewer: Trek Thru-Skew
Rear Hub: Shimano TC500-HM
Rear Skewer: Bontrager Switch thru axle, removable lever
Rims: Bontrager Kovee, double-wall, Tubeless-Ready, 23 mm width, Presta valve (32-hole or 28-hole depending on size)
Spokes: 14 g stainless steel, black
Tyres: Bontrager E6 Hard-Case Lite, reflective strip, 27.5x2.40"
Max Tyre Size: Frame: 27.5x2.40", Fork: see manufacturer
E-System
Battery: Bosch PowerTube 800 Wh, smart system
Motor: Bosch Performance Line, 250 W, 75 Nm, 20 mph (25 km/h in Europe)
Computer: Bosch Purion 200
Charger: Bosch standard 2A, 230V, smart system
E-bike Classification: Class 1
Drivetrain
Shifter: Shimano U4000, 9-speed
Crank: ProWheel alloy, 170 mm length
Chainring: Alloy, with 40T narrow-wide steel ring, alloy guard
Cassette: Shimano LINKGLIDE LG300, 11-46t, 9-speed
Chain: Shimano LG500, 9/10/11-speed
Pedals: Bontrager City pedals
Max Chainring Size: 1x: 50T
Components & Brakes
Saddle: Bontrager Boulevard
Seatpost: Alloy, suspension, 31.6 mm, 300 mm length
Handlebar: Alloy, 31.8 mm clamp, 25 mm rise, 630 mm width
Grips: Trek Ergonomic Comp, lock-on
Stem: Bontrager alloy, 31.8 mm clamp, adjustable rise, Blendr compatible, 80 mm length
Brakes: Shimano MT200 hydraulic disc
Brake Rotors: Shimano EM300, CentreLock, 180 mm
Max Rotor Size: Frame: 203 mm, Fork: see fork manufacturer
Accessories
Front Light: Trek LED, 400 lumen low / 800 lumen high
Rear Light: Trek LED taillight
Kickstand: Pletscher Comp Flex 40
Weight
Weight: Size L – 26.80 kg / 59.09 lb (excluding battery)
Weight Limit: Maximum total weight (bike + rider + cargo): 136 kg / 300 lb
We reserve the right to make changes to specifications without notice due to supply chain constraints.
Bike and frame weights are based on pre-production painted frames; final production weights may vary.
