Frameset
Frame
Alpha Smooth Aluminium, Bosch Compact PowerTube and belt drive, internal cable routing, post-mount disc
Fork
SR Suntour NVX30, coil spring, preload adjuster, 100 mm QR, 60 mm travel
Wheels
Hub front
Alloy, CenterLock disc, 100 mm thru axle
Hub rear
Shimano Nexus C3001, CenterLock, 7-speed
Rim
Bontrager Connection, double-wall, 32-hole, 20 mm width, Presta valve
Spokes
14 g stainless steel, black
Tyre
Bontrager H2 Comp, wire bead, 30 tpi, 27.5x2.00"
E-system
Battery
Bosch CompactTube 400 Wh
Charger
Bosch standard 4A, 230V, smart system
Computer
Bosch Purion 200
Motor
Bosch Active Line Plus, 50 Nm
Drivetrain
Shifter
Shimano Nexus Revo, 7-speed
Crank
ProWheel alloy, 170 mm length
Cassette
Gates CDC CentreTrack, 22T
Pedal
Slip-proof pedals with reflectors
Components
Saddle
Bontrager Boulevard
Seatpost
Alloy, suspension, 31.6 mm, 300 mm length
Handlebar
Alloy, 31.8 mm clamp, 25 mm rise, 630 mm width
Grips
Herrmans Clik, ergonomic, lock-on
Stem
Size S, M: Bontrager alloy, 31.8 mm clamp, adjustable rise, Blendr-compatible, 85 mm length
Size L: Bontrager alloy, 31.8 mm clamp, adjustable rise, Blendr-compatible, 105 mm length
Brake
Shimano MT200 hydraulic disc
Brake rotor
Shimano RT10, CenterLock, 160 mm
Accessories
Light
Size S, M, L: Spanninga SOLO for e-bike
Size S, M, L: Herrmans H-Black MR5-E, 140 Lumen, 40 Lux, LED, headlight
Kickstand
Pletscher Comp Flex 18
Cargo rack
MIK-compatible alloy rear rack
Mudguard
SKS wide, plastic
Weight
Weight
M - 26.10 kg / 57.55 lbs
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb)
Notes
We reserve the right to make changes to the product information contained on this site at any time without notice, including equipment, specifications, models, colours, materials, and pricing. Compatible parts may be substituted due to supply chain issues. Bike and frame weights are based on pre-production painted frames and may vary in final production.
