Please note – spec applies to all sizes unless listed separately
Frameset
Frame: Alpha Smooth Aluminium, Removable Integrated Battery, internal cable routing, Motor Armour, post-mount disc, 135x5 mm QR
Fork: SR Suntour XCR32, coil spring, preload adjuster, lockout, 100 mm QR, 63 mm travel
Wheels
Hub front: Shimano TX505, CenterLock
Hub rear: Shimano FH-QC300-HM, 32-hole, CentreLock, 8-/9-/10-/11-speed, 135x5 mm QR
Rim: Bontrager Kovee, double-wall, Tubeless Ready, 28-hole, 23 mm width, Presta valve
Tyre: Bontrager LT4 Expert, reflective strip, wire bead, 60 tpi, 27.5x2.40"
E-system
Charger: Bosch standard 4A, 230V, smart system
Computer: Bosch Purion 200
Motor: Bosch Performance Line, 250 W, 75 Nm, 20 mph (25 km/h in Europe)
Drivetrain
Shifter: Shimano U4000, 9-speed
Rear derailleur: Shimano CUES U4000
Crank:
Size XS, S, M: ProWheel alloy, 170 mm length
Size L, XL: ProWheel alloy, 175 mm length
Chainring: ProWheel 38T narrow/wide steel, w/alloy guard
Cassette: Shimano LINKGLIDE LG300, 11-46, 9-speed
Chain: Shimano LG500, 9/10/11-speed
Pedal: VP-536 nylon platform
Max. chainring size: 1x: 42T
Components
Saddle: Selle Royal Vivo Moderate Ergo
Seatpost: Alloy, suspension, 31.6 mm, 300 mm length
Handlebar: Alloy lowriser, 31.8 mm, 25 mm rise, 11-degree backsweep, 690 mm width
Grips: Bontrager XR Trail Comp, nylon lock-on
Stem:
Size XS: Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 60 mm length
Size S: Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 70 mm length
Size M: Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 80 mm length
Size L: Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 90 mm length
Size XL: Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 100 mm length
Brake: Shimano MT200 hydraulic disc
Brake rotor:
Size XS, S, M, L, XL: Shimano RT30, CentreLock, 180 mm
Size XS, S, M, L, XL: Shimano EM300, CentreLock, 180 mm
Rotor size: Max brake rotor sizes: 180 mm front and rear
Accessories
Light:
Size XS, S, M, L, XL: Spanninga SOLO for e-bike, taillight
Size XS, S, M, L, XL: Herrmans H-Black MR5-E, 140 Lumen, 40 Lux, LED, headlight
Kickstand: Pletscher Comp Flex 18
Cargo rack: MIK-compatible alloy rear rack, maximum load 25 kg
Mudguard:
Size XS, S, M, L, XL: SKS plastic, front
Size XS, S, M, L, XL: SKS plastic, rear
Weight
Weight: M - 23.50 kg / 51.81 lbs (excluding battery)
Weight limit: This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb)
