Frameset
Frame: High-performance hydroformed alloy, Removable Integrated Battery, internal cable routing, Motor Armour, post-mount disc
Fork: SR Suntour NVX30, coil spring, preload adjuster, 100 mm QR, 60 mm travel
Wheels
Front hub: Alloy, CenterLock disc, 100 mm thru axle
Rear hub: Shimano Nexus C7000, 5-speed
Rims: Bontrager Connection, double-wall, 32-hole, 20 mm width, Presta valve
Spokes: 14 g stainless steel, black
Tyres: Bontrager E6 Hard-Case Lite, reflective strip, 27.5x2.40"
E-system
Charger: Bosch standard 4A, 230V, smart system
Controller: Bosch Intuvia 100, smart system
Computer: Bosch LED remote, smart system
Motor: Bosch Performance Line, 250 W, 75 Nm, 20 mph (25 km/h in Europe)
Drivetrain
Shifter: Shimano Nexus C7000, 5-speed
Crank:
- Sizes S, M: ProWheel alloy, 170 mm
- Sizes L, XL: ProWheel alloy, 175 mm
Chainring: ProWheel 38T narrow/wide steel, with alloy guard
Cassette: Shimano C7000 sprocket for Nexus, 27T
Chain: Shimano HG40, 6/7/8-speed
Pedals: Bontrager City pedals
Components
Saddle: Bontrager Boulevard
Seatpost: Alloy, suspension, 31.6 mm, 300 mm
Handlebar: Alloy, 31.8 mm clamp, 25 mm rise, 630 mm width
Grips: Bontrager Satellite Elite, alloy lock-on
Stem:
- Sizes S, M: Bontrager alloy, adjustable rise, Blendr-compatible, 85 mm
- Sizes L, XL: Bontrager alloy, adjustable rise, Blendr-compatible, 105 mm
Brakes: Shimano MT200 hydraulic disc
Brake rotors:
- All sizes: Shimano EM300, CenterLock, 160 mm
- All sizes: Shimano RT10, CenterLock, 160 mm
Accessories
Lights:
- All sizes: Spanninga SOLO for e-bike
- All sizes: Herrmans H-Black MR5-E
Kickstand: Pletscher Comp Flex 18
Cargo rack: Alloy rear rack, 25 kg max load
Mudguards:
- All sizes: SKS plastic, rear
- All sizes: SKS plastic, front
Weight
Weight limit: 136 kg (300 lb) total (bike, rider, cargo)
