Frameset
Frame:
M, L, XL – Alpha Smooth Aluminium, Removable Integrated Battery, internal cable routing, Motor Armour, post-mount disc, 135x5 mm QR
XXL – High-performance hydroformed alloy, Removable Integrated Battery, internal cable routing, Motor Armour, post-mount disc
Fork: SR Suntour NVX30, coil spring, preload adjuster, 100 mm QR, 60 mm travel
Wheels & Tyres
Front Hub: Shimano Tourney HB-QC300, CenterLock
Rear Hub: Shimano FH-QC300-HM, 32-hole, CentreLock, 8-/9-/10-/11-speed, 135x5 mm QR
Rim: Bontrager Connection, double-wall, 32-hole, 20 mm width, Presta valve
Tyre: Bontrager E6 Hard-Case Lite, reflective strip, 27.5x2.40"
Max Tyre Size: 27.5x2.40" with or without mudguards
E-system
Motor: Bosch Performance Line, 250 W, 75 Nm, 20 mph (25 km/h in Europe)
Charger: Bosch standard 2A, 230V, smart system
Computer: Bosch Purion 200
Drivetrain
Shifter: Shimano U4000, 9-speed
Rear Derailleur: Shimano CUES U4000
Crank:
- M: ProWheel alloy, 170 mm length
- L, XL, XXL: ProWheel alloy, 175 mm length
Chainring: ProWheel 38T narrow/wide steel with alloy guard
Cassette: Shimano CUES LG300, LINKGLIDE, 11-36, 9-speed
Chain: Shimano LG500, 9/10/11-speed
Pedal: slip-proof pedals with reflectors
Max Chainring Size: 1x: 46T
Components
Saddle: Selle Royal Nuvola
Seatpost: Alloy, suspension, 31.6 mm, 300 mm length
Handlebar: Bontrager aluminium touring
Grips: Herrmans Clik, ergonomic, lock-on
Stem:
- M: 85 mm
- L, XL, XXL: 105 mm
Brake: Shimano MT200 hydraulic disc
Brake Rotor:
- M, L, XL, XXL: Shimano EM300, CenterLock, 160 mm
- M, L, XL, XXL: Shimano RT10, CenterLock, 160 mm
Rotor Size: Max 180 mm front and rear
Accessories
Light:
- M, L, XL, XXL: Spanninga SOLO for e-bike
- M, L, XL, XXL: Herrmans H-Black MR5-E, 140 Lumen, 40 Lux, LED, headlight
Kickstand: Pletscher Comp Flex 18
Cargo Rack: Alloy rear rack, 25 kg max weight
Mudguards:
- M, L, XL, XXL: SKS plastic, front
- M, L, XL, XXL: SKS plastic, rear
Weight
Weight: M – 27.29 kg / 60.17 lb
Weight Limit: 136 kg (300 lb) total (bike, rider, cargo)
