Please note – spec applies to all sizes unless listed separately
Frameset
Frame: Alpha Gold Aluminium, tapered head tube, internal derailleur & dropper post routing, ISCG 05, threaded BB, Boost148, 12 mm thru axle
Fork:
Size XS: Fox Rhythm 36, Float EVOL air spring, GRIP damper, tapered steerer, 44 mm offset, Boost110, 15 mm Kabolt axle, 140 mm travel
Max compatible fork travel: 150 mm
Wheels
Hub front: Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Boost110, 15 mm thru axle
Hub rear: Bontrager alloy, sealed bearing, 6-bolt, Rapid Drive 108, Shimano MicroSpline freehub, Boost148, 12 mm thru axle
Skewer rear: Bontrager Switch thru-axle, removable lever
Rim: Bontrager Line Comp 30, Tubeless Ready, 28-hole, Presta valve
Tyre:
Size XS: Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewalls, aramid bead, 120 tpi, 27.5x2.60"
Sizes S, M, M/L, L, XL: Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewalls, aramid bead, 120 tpi, 29x2.60"
Tyre part: Bontrager TLR sealant, 180 ml/6 oz
Rim strip: Bontrager TLR
Max tyre size: Frame: 29x2.60" (XS: 27.5x2.60"), Fork: see manufacturer
Drivetrain
Shifter: Shimano SLX M7100, 12-speed
Rear derailleur: Shimano XT M8100, long cage
Crank:
Sizes XS, S, M, M/L, L: E*thirteen Helix, 30T steel ring, 73 mm spindle length, 52 mm chainline, 170 mm length
Size XL: E*thirteen Helix, 30T steel ring, 73 mm spindle length, 52 mm chainline, 175 mm length
Bottom bracket: Shimano SM-BB52, 73 mm, threaded external bearing
Cassette: Shimano SLX M7100, 10-51, 12-speed
Chain: Shimano Deore M6100, 12-speed
Max. chainring size: 52 mm chainline: 32T, 55 mm chainline: 34T
Components
Saddle: Bontrager Arvada, hollow chromoly rails, 138 mm width
Seatpost:
Sizes XS, S: TranzX JD-YSP18, 100 mm travel, internal routing, 31.6 mm, 361 mm length
Size M: TranzX JD-YSP18, 130 mm travel, internal routing, 31.6 mm, 425 mm length
Sizes M/L, L, XL: TranzX JD-YSP18, 150 mm travel, internal routing, 31.6 mm, 470 mm length
Handlebar:
Sizes XS, S: Bontrager Line, alloy, 35 mm, 27.5 mm rise, 750 mm width
Sizes M, M/L, L, XL: Bontrager Line, alloy, 35 mm, 27.5 mm rise, 780 mm width
Grips: Bontrager XR Trail Comp, nylon lock-on
Stem:
Sizes XS, S: Bontrager Elite, 35 mm, 0-degree, 35 mm length
Sizes M, M/L, L, XL: Bontrager Elite, 35 mm, 0-degree, 45 mm length
Head set: FSA IS-2, 1-1/8" top, 1.5" bottom
Brake:
Sizes XS, S, M, M/L, L, XL: Shimano M6120 4-piston hydraulic disc
Sizes XS, S, M, M/L, L, XL: Shimano 4-piston hydraulic disc, M6100 lever, M6120 calliper
Brake rotor:
Sizes XS, S, M, M/L, L, XL: Shimano RT66, 6-bolt, 180 mm
Sizes XS, S, M, M/L, L, XL: Shimano RT66, 6-bolt, 203 mm
Weight
Weight: M – 28.95 lb / 13.13 kg (with TLR sealant, no tubes)
Weight limit: This bike has a maximum total weight limit (combined weight of bicycle, rider and carg
