Frameset
Frame: Orbea Terra Hydro Disc, hydroformed triple-butted aluminium, HS 1.5", PF BB, DT internal cable routing, 27.2mm seat tube, MMS mount system, Thru Axle 12x142mm rear, thread M12x2 P1
Fork: Orbea Terra ICR, full carbon, 1-1/8" – 1.5" tapered head tube compatible, Thru Axle 12x100mm, thread M12x2 P1
Steerer Tube: FSA 1-1/2" Integrated Aluminium Cup
Drivetrain
Crankset: Shimano CUES U6030, 40T
Shifters: Shimano CUES U3030
Cassette: Shimano CS-LG300, 11–48T, 10-Speed
Rear Derailleur: Shimano CUES U6000 GS Shadow
Chain: Shimano LG500
Cockpit & Brakes
Handlebar: OC Gravel GR31-R, Rise 15, Reach 70, Drop 110
Stem: OC Road Performance RP23, -5º
Brakes: Jagwire RideRever Mechanical Disc
Brakes Configuration: N/A
Wheels & Tyres
Wheels: Alloy, Tubeless Ready, 700c, 21c internal width
Tyres: Vittoria Terreno T30 Fine Loose Gravel, 700x40c
Front Wheel Axle: Orbea Thru Axle 12x100mm M12x2 P1 Solid
Rear Wheel Axle: Orbea Thru Axle 12x142mm M12x2 P1 Solid, inner threaded
Components
Seatpost: SP 0.2 Carbon, 27.2mm, Setback 20
Saddle: Fizik Terra Argo X7, Aluminium Rail, 150mm
Accessories
Handlebar Tape: Orbea EVA
Mudguard: N/A
