Frameset
Frame
Alpha Smooth Aluminium, Bosch Compact PowerTube and belt drive, internal cable routing, post-mount disc
Fork
Verve alloy, threadless steel steerer, ThruSkew QR
Wheels
Hub front
Size S, M, L: Shimano Tourney HB-QC300, CenterLock
Size S, M, L: Shimano TX505, CenterLock
Skewer front
132x5 mm QR, ThruSkew
Hub rear
Shimano Nexus C3001, CenterLock, 7-speed
Rim
Bontrager Connection, double-wall, 32-hole, 20 mm width, Presta valve
Spokes
14 g stainless steel, black
Tyre
Bontrager H2 Comp, wire bead, 30 tpi, 27.5x2.00"
Max tyre size
650 x 50 mm
E-system
Battery
Bosch CompactTube 400 Wh
Charger
Bosch standard 2A, 230V, smart system
Computer
Bosch LED remote, smart system
Motor
Bosch Active, smart system, 40Nm, 20 mph / 32 km/h max assist (25 km/h max assist in EU and APAC)
Drivetrain
Shifter
Shimano Nexus Revo, 7-speed
Crank
ProWheel alloy, 170 mm length
Chainring
ProWheel 38T narrow/wide steel, with alloy guard
Cassette
18T
Chain
Shimano HG40, 6/7/8-speed
Pedal
Slip-proof pedals with reflectors
Max. chainring size
1x: 40T
Components
Saddle
Selle Royal Nuvola
Seatpost
Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length
Handlebar
Alloy, 31.8 mm clamp, 25 mm rise, 630 mm width
Grips
Herrmans Clik, ergonomic, lock-on
Stem
Size S, M: Bontrager alloy, 31.8 mm clamp, adjustable rise, Blendr-compatible, 85 mm length
Size L: Bontrager alloy, 31.8 mm clamp, adjustable rise, Blendr-compatible, 105 mm length
Brake
Shimano MT200 hydraulic disc
Brake rotor
Shimano RT10, CenterLock, 160 mm
Accessories
Light
Size S, M, L: Herrmans MR-GO, 100 lumen, 35 lux
Size S, M, L: Spanninga SOLO for e-bike
Kickstand
Pletscher Comp Flex 18
Cargo rack
MIK-compatible alloy rear rack
Mudguard
SKS wide, plastic
Weight
Weight
M - 24.30 kg / 53.58 lbs
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb)
Notes
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
