Please note – spec applies to all sizes unless listed separately.
Frameset
Frame: 800 Series OCLV Carbon, TQ drive system, tapered head tube, rear IsoSpeed, internal routing, flat mount disc, mudguard mounts, 142x12 mm thru axle
Fork:
Size 50, 52, 54, 56, 58, 60, 62: Domane+ carbon, tapered carbon steerer, internal brake routing, mudguard/fender mounts, flat mount disc, 12x100 mm thru axle
E-system
Battery: TQ 360 Wh
Charger: TQ 4A charger
Computer: TQ LED display with Bluetooth & ANT+ connectivity
Motor: TQ-HPR60, 60 Nm, 250 W continuous rated power, 350 W peak power
Drivetrain
Shifter: Shimano Ultegra R8170 Di2, 12-speed
Front Derailleur: Shimano Ultegra R8150 Di2, braze-on, down swing
Rear Derailleur: Shimano Ultegra R8150 Di2, 34T max cog
Crank:
Size 50, 52: Praxis Carbon, 165 mm length
Size 54, 56: Praxis Carbon, 170 mm length
Size 58, 60, 62: Praxis Carbon, 172.5 mm length
Chainring: Praxis, 50/34T, 12-speed
Cassette: Shimano Ultegra R8101, 11–34, 12-speed
Chain: Shimano Ultegra / XT M8100
Max Chainring Size: 1x: 46T, 2x: 52/36
Wheels & Tyres
Front Wheel: Bontrager Aeolus Pro 37, OCLV Carbon, Tubeless Ready, 37 mm rim depth, 100 x 12 mm thru axle
Rear Wheel: Bontrager Aeolus Pro 37, OCLV Carbon, Tubeless Ready, 37 mm rim depth, Shimano 11-speed freehub, 142 x 12 mm thru axle
Front Skewer: Bontrager Switch thru-axle
Rear Skewer: Bontrager Switch thru-axle, removable lever
Tyre: Bontrager Kwaremont RSL TLR, tubeless ready, folding bead, Race Dual-Compound, 320 tpi, 700 x 32 mm
Tyre Part: Bontrager TLR sealant, 180 ml / 6 oz
Rim Strip: Bontrager TLR
Max Tyre Size: 40 mm without mudguards, 35 mm with mudguards
Components
Saddle: Verse Short Pro, carbon rails, 145 mm width
Seatpost:
Size 50, 52, 54, 56: KVF aero carbon seatpost, 20 mm offset, 280 mm length
Size 58, 60, 62: KVF aero carbon seatpost, 20 mm offset, 320 mm length
Handlebar:
Size 50, 52: Bontrager Pro IsoCore VR-SF, 40 cm
Size 54, 56: Bontrager Pro IsoCore VR-SF, 42 cm
Size 58, 60, 62: Bontrager Pro IsoCore VR-SF, 44 cm
Handlebar Tape: Trek EcoTack
Stem:
Size 50: Trek RCS Pro, -7°, 80 mm
Size 52, 54: Trek RCS Pro, -7°, 90 mm
Size 56, 58: Trek RCS Pro, -7°, 100 mm
Size 60, 62: Trek RCS Pro, -7°, 110 mm
Brake Rotor: Shimano CL800, CentreLock, 160 mm
Rotor Size: Max 180 mm front, 160 mm rear
Weight & Limits
Weight: Size 56 – 12.65 kg / 27.89 lb (with TLR sealant, no tubes)
Weight Limit: Maximum total weight (bike + rider + cargo) 125 kg / 275 lb
