Please note – spec applies to all sizes unless listed separately
Frameset
Frame: OCLV Mountain Carbon, high main pivot, idler pulley, internal storage, angle-adjust headset, adjustable leverage rate, integrated frame protection, internal routing, alloy rocker link, ISCG 05, Active Braking Pivot, UDH, 148x12 mm thru axle, 170 mm travel
Fork: RockShox ZEB Select+, DebonAir spring, Charger 3.1 RC2 damper, tapered steerer, 44 mm offset, Boost110, Maxle Stealth, 170 mm travel
Shock: RockShox Vivid Select+, 230 mm x 65 mm
Max compatible fork travel: 190 mm (606 mm axle-to-crown), S: 190 mm (587 mm axle-to-crown)
Wheels
Tyre:
Sizes S, M, ML, L, XL: Bontrager Brevard RSL SE, Tubeless Ready, triple compound, aramid bead, 60 tpi, 27.5 x 2.5"
Sizes M, ML, L, XL: Bontrager Brevard RSL SE, Tubeless Ready, triple compound, aramid bead, 60 tpi, 29 x 2.5"
Tyre part: Bontrager TLR sealant, 180 ml/6 oz
Max tyre size: Frame: 2.50", Fork: See manufacturer
Drivetrain
Shifter: Shimano XT Di2 M8250, 12-speed
Rear derailleur: Shimano XT M8250, long cage
Crank: Shimano XT 8200, 30T, 55 mm chain-line, 170 mm length
Bottom bracket: Shimano BB-MT501 BSA
Cassette: Shimano XT M8200, 10-51, 12-speed
Chain: Shimano XT M8100, 12-speed
Max. chainring size: Max: 34T (oval – 32T), Min: 28T
Components
Saddle: Verse Short Comp, steel rails, 145 mm width
Seatpost:
Size S: Bontrager Line Dropper, 150 mm travel, MaxFlow, internal routing, 34.9 mm, 410 mm length
Size M: Bontrager Line Dropper, 170 mm travel, MaxFlow, internal routing, 34.9 mm, 450 mm length
Sizes ML, L, XL: Bontrager Line Dropper, 200 mm travel, MaxFlow, internal routing, 34.9 mm, 515 mm length
Handlebar: Bontrager Line Pro, OCLV Carbon, 35 mm, 27.5 mm rise, 820 mm width
Grips: Trek Line Pro, lock on
Stem: Bontrager Line Pro, 35 mm, Blendr-compatible, 0-degree, 35 mm length
Brake: Shimano XT M8200 4-piston hydraulic disc
Brake rotor: Shimano RT86, 6-bolt, 203 mm
Rotor size: Max brake rotor sizes – Frame: 220 mm, Fork: see fork manufacturer
Weight
Weight limit: This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb)
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
