*Please note – spec applies to all sizes unless listed separately
Frameset
Frame High-performance hydroformed alloy, Removable Integrated Battery, internal cable routing, Motor Armour, post-mount disc
Fork SR Suntour NVX30, coil spring, preload adjuster, 100 mm QR, 60 mm travel
Wheels
Hub front Alloy, CenterLock disc, 100 mm thru axle
Hub rear Shimano Nexus, 8-speed, internal gear hub
Rim Bontrager Connection, double-wall, 32-hole, 20 mm width, Presta valve
Spokes 14 g stainless steel, black
Tyre Bontrager E6 Hard-Case Lite, reflective strip, 27.5x2.40"
E-system
Charger Bosch standard 2A, 230V, smart system
Computer Bosch Purion 200
Motor Bosch Active Line Plus, 50 Nm
Drivetrain
Shifter Shimano Nexus Revo, 8-speed
Crank ProWheel alloy, 170 mm length
Chainring ProWheel 38T narrow/wide steel, w/alloy guard
Cassette 18T
Chain Shimano HG40, 6/7/8-speed
Pedal slip-proof pedals with reflectors
Components
Saddle Selle Royal Nuvola
Seatpost Alloy, suspension, 31.6 mm, 300 mm length
Handlebar Alloy, 31.8 mm clamp, 25 mm rise, 630 mm width
Grips Herrmans Clik, ergonomic, lock-on
Stem Bontrager alloy, 31.8 mm clamp, adjustable rise, Blendr-compatible, 105 mm length
Brake Shimano MT200 hydraulic disc
*Brake rotor
Size: L, XL, XXL
Shimano EM300, CenterLock, 160 mm
Size: L, XL, XXL
Shimano RT10, CenterLock, 160 mm
Accessories
*Light
Size: L, XL, XXL
Spanninga SOLO for e-bike
Size: L, XL, XXL
Herrmans MR4, 120-lumen LED
Kickstand Pletscher Comp Flex 18
Cargo rack Alloy rear rack, 25 kg max weight
*Mudguard
Size: L, XL, XXL
SKS plastic, rear
Size: L, XL, XXL
SKS plastic, front
Weight
Weight L - 26.60 kg / 58.65 lbs (excluding battery)
Weight limit This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
