*Please note – spec applies to all sizes unless listed separately
Frameset
Frame: OCLV Mountain Carbon, removable battery, angle-adjust headset, adjustable leverage rate, guided internal routing, interchangeable alloy rocker links, interchangeable lower shock mount, downtube guard, shuttle guard, ABP, UDH, Boost148, adaptable travel 145–160 mm
Fork: Fox Factory 38, Float EVOL air spring, GRIP X2 damper, 44 mm offset, Boost 110, 15 mm Kabolt X axle, 170 mm travel
Shock: Fox DHX2, 205 mm x 65 mm
Suspension part:
Size: S – Fox steel coil spring, 250 lbs
Size: M – Fox steel coil spring, 350 lbs
Size: L – Fox steel coil spring, 400 lbs
Size: XL – Fox steel coil spring, 450 lbs
Size: XXL – Fox steel coil spring, 500 lbs
Wheels
Wheel front: Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15 mm thru-axle, 29"
Wheel rear: Bontrager Line Comp 30, Tubeless Ready, Rapid Drive 108, 6-bolt, Shimano Micro Spline freehub, Boost148, 12 mm thru-axle, 29"
Skewer rear: Bontrager Switch thru-axle, removable lever
Tyre:
Size: S, M, L, XL, XXL – Maxxis Assegai, tubeless-ready, 3C, EXO+ casing, MAXXGRIP, folding bead, 29x2.5''
Size: S, M, L, XL, XXL – Maxxis Minion DHR II, tubeless-ready, 3C, EXO+ casing, MAXXTERRA, folding bead, 29x2.5''
Tyre part: Bontrager TLR sealant, 180 ml/6 oz
Max tyre size: Frame: 29x2.50", Fork: See manufacturer
E-system
Battery: TQ 580Wh
Charger: TQ 4A charger
Controller: TQ color LED display with Bluetooth & ANT+ connectivity
Motor: TQ-HPR60, 60 Nm, 300 watt maximum continuous rated power, 350 watt peak power
Drivetrain
Shifter: Shimano XT Di2 M8250, 12-speed
Rear derailleur: Shimano XT Di2 M8260, 12-speed
Crank arm: E*thirteen E*spec Plus, 160 mm length
Chainring: E*Thirteen Helix Core Steel 32T steel, 55 mm chainline
Cassette: Shimano XT M8200, 10-51, 12-speed
Chain: Shimano Ultegra/XT M8100, 12-speed
Max. chainring size: 1x: 34T, min 30T
Components
Saddle: Verse Short Comp, steel rails, 145 mm width
Seatpost:
Size: S – Bontrager Line Dropper, 150 mm travel, MaxFlow, internal routing, 34.9 mm, 410 mm length
Size: M – Bontrager Line Dropper, 170 mm travel, MaxFlow, internal routing, 34.9 mm, 450 mm length
Size: L, XL, XXL – Bontrager Line Dropper, 200 mm travel, MaxFlow, internal routing, 34.9 mm, 515 mm length
Handlebar: Race Face ERA, carbon, 35 mm, 27.5 mm rise, 800 mm width
Grips: Trek Line Elite, lock-on
Stem: Bontrager Elite, 35 mm, 0-degree, 45 mm length
Brakes
Brake: Shimano XT M8220 4-piston hydraulic disc
Brake rotor: Shimano RT86, 6-bolt, 203 mm
Rotor size: Max brake rotor sizes – Frame: 203 mm, min 180 mm, Fork: see fork manufacturer
Weight
Weight: M – 20.68 kg / 45.6 lbs (with TLR sealant, no tubes)
Weight limit: 136 kg (300 lb)
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.
