Frameset
Frame: Orbea Denna, Thru Axle 12mm x 142mm rear, thread M12xP1, internal cable routing.
Fork: Orbea Denna OMR ICR, full carbon, 1-1/8" - 1,5" tappered head tube compatible, Thru axle 12x100mm, thread M12xP1
Steerer Tube: FSA 1-1/2" Integrated Aluminium Cup
Ebike
Battery: Orbea Internal 420Wh
Range Extender: N/A
Motor: Shimano EP600
Charger: Orbea 2.Generation eBike Smart charger 42V/2-4A
Remote: EN600-L
Drivetrain
Chainring: Alloy EP8 42t
Crank: Shimano Steps EM600
Shifters: Shimano U6030
Cassette: Shimano CS-LG400 11-50t 11-Speed
Rear Derailleur: Shimano Cues U6000 GS Shadow
Chain: Shimano LG500
Chainguide: Orbea eBike chainguide
Cockpit & Brakes
Handlebar: OC Road Performance RP31-R, Rise 15, Reach 70, Drop 125
Stem: OC Road Performance RP23, -5º
Brakes: Shimano RS405 Hydraulic Disc
Rotors: N/A
Brakes Configuration: N/A
Wheels & Tyres
Wheels: Alloy, Tubeless, 700c, 21c
Tyres: Vittoria Terreno Dry Gravel G2.0 TLR 700x45c
Front Wheel Axle: Orbea Thru Axle 12x100mm M12xP1 Hollow
Rear Wheel Axle: Orbea Thru Axle 12x142mm M12xP1 Solid inner threaded
Components
Seatpost: SP 0.2 Carbon, 27.2mm, Setback 0
Saddle: Selle San Marco Shortfit 2.0 Start Up Off Road
Accessories
Mudguard: N/A
Handlebar Tape: Orbea Anti-Slippery/Shock Proof
Storage: OC Frame Bag for Denna
