Frameset
Frame: Orbea Gain Carbon OMR monocoque structure, Integrated Seat clamp with STVZO light, ICR cable routing, Thru Axle 12x142mm rear, thread M12x2 P1, Flat Mount disc, 700x35 max tyre, BB386 EVO, Mahle X20 AMC plug.
Fork: Gain OMR carbon fork, 700x35 maximun tyre, Flat Mount disc, Thru Axle 12x100mm, thread M12x2 P1
Steerer Tube: FSA 1-1/2" Integrated Aluminium Cup
Ebike
Battery: Mahle iX350 36V 353Wh
Range Extender: N/A
Motor: Mahle motor hub X20, ALC
Display: Mahle Pulsar One monochrome ANT+ LEV
Charger: Mahle Active Charger up to 4A
Remote: Mahle ONE Head Unit (BT/ANT+)
Remote2: Mahle Handlebar Dual eShifter
Drivetrain
Crankset: Shimano Ultegra R8100 34x50t
Shifters: Shimano ST-8170
Cassette: Shimano Ultegra R8100 11-30t 12-Speed
Rear Derailleur: Shimano Ultegra Di2 R8150
Front Derailleur: Shimano Ultegra Di2 R8150
Chain: Shimano M8100
Cockpit & Brakes
Handlebar: OC Road Performance RP11-R Carbon, Rise 15, Reach 70, Drop 125
Stem: OC Road Performance RP10, -8º
Brakes: Shimano R8170 Hydraulic Disc
Rotors: N/A
Brakes Configuration: N/A
Wheels & Tyres
Wheels: Carbon 42, Tubeless, 21c
Tyres: Pirelli P ZERO™ Race X SmartEVO TLR 700x30c
Front Wheel Axle: Orbea Thru Axle 12x100mm M12x2 P1 Lite
Rear Wheel Axle: Orbea Thru Axle 12x142mm M12x2 P1 Lite
Components
Seatpost: OC Performance XP10-S Carbon, 27.2mm, Setback 20
Saddle: Fizik Vento Antares R3 Kium Rail 140mm
Accessories
Front Light: Front position light, on display holder, COB Led, On/Off, 60 Lumen, ECE50.
Rear Light: Rear position light, on saddle clamp, COB Led, On/Off, 12 Lumen. STVZO
Handlebar Tape: Orbea Anti-Slippery/Shock Proof
